0.6/1kv overhead abc cable
22kv abc aerial overhead cable is with following features:
22kv abc aerial overhead cable is consisting of standard aluminium conductors or aluminum alloy, insulated XLPE insulation.
One sheath lighting aluminum conductor with XLPE insulation (optional)
One messenger Al-alloy conductor (bare or covered)
The messenger conductor can be of galvanized steel wire also.
The purpose of messenger wire is A) It acts as load bearing wire. B) It acts as earth or neutral conductor.
To be used at voltages of 600V phase-to-phase or less and at conductor temperatures not to exceed 75°C for polyethylene insulated conductors or 90°C for crossliked polyethylene(XLPE) insulated conductors.
It meets or exceeds the following specifications: 1. Aluminum Wire, 1350-H19 for Electrical Purposes. 2. Aluminum Conductors, Concentric-Lay-Stranded. 3. Aluminum Conductor, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR)
4. Concentric-Lay-Stranded 6201-T81 Conductors
5. It meets or exceeds all applicable requirements of ANSI/ICEA S-76-474.
22kv abc aerial overhead cable with ACSR messenger Core
|
Nominal section area(sqmm)
|
Conductor structure |
Insulation material
|
Insulation Thickness(mm)
|
Approx. Overall Diameter(mm)
|
Approx. weight (kg/km)
|
Packing meters per drum
|
||
|
Phase (Compacted AL) |
Neutral (bare ACSR) |
|||||||
|
(No./mm)
|
Aluminum (No./mm)
|
Steel (No./mm)
|
||||||
|
1x16+16 |
7/1.72 |
6/1.72 |
1/1.72 |
XLPE |
1.2 |
12.5 |
121.9 |
250-4000m |
|
1x25+25 |
7/2.15 |
6/2.15 |
1/2.15 |
1.2 |
14.9 |
182.2 |
250-4000 |
|
|
1x35+35 |
7/2.54 |
6/2.54 |
1/2.54 |
1.4 |
17.5 |
254.7 |
250-3500m |
|
|
1x70+70 |
19/2.15 |
12/2.15 |
7/2.15 |
1.4 |
23.6 |
382.2 |
250-3000m |
|
|
1x95+95 |
19/2.54 |
12/2.54 |
7/2.54 |
1.6 |
27.6 |
528.2 |
250-3000m |
|
|
2x16+16 |
7/1.72 |
6/1.72 |
1/1.72 |
1.2 |
14.2 |
187.6 |
250-4000m |
|
|
2x25+25 |
7/2.15 |
6/2.15 |
1/2.15 |
1.2 |
16.7 |
273.8 |
250-3500m |
|
|
2x35+35 |
7/2.54 |
6/2.54 |
1/2.54 |
1.4 |
19.7 |
386.9 |
250-3500m |
|
|
2x70+70 |
19/2.15 |
12/2.15 |
7/2.15 |
1.4 |
26.1 |
617.2 |
250-3000m |
|
|
2x95+95 |
19/2.54 |
12/2.54 |
7/2.54 |
1.6 |
30.5 |
850.9 |
250-3500m |
|
|
3x70+70 |
19/2.15 |
12/2.15 |
7/2.15 |
1.4 |
29.7 |
1024.3 |
250-3000m |
|
|
3x95+95 |
19/2.54 |
12/2.54 |
7/2.54 |
1.6 |
34.6 |
1413.7 |
250-3000m |
|
MOQ, Capacity& Payment method
For electric wire, aerial cable and power cable, the Minimum Order Quantity is 1000 meters each type. The capacity is 20 kilometers per day.
For electric conductor(AAC,ACSR,AAAC,AASC) for transmission line, the Minimum Order Quantity is 1 ton each type. The capacity is 50 tons per day.
Our payment term is 30% deposit in advance, 70% rest against copy of B/L; or 100% irrevocable L/C at sight
