2 channel 50MHZ Original Professional Oscilloscopes Price unit Digital osciloscopio
1. Dual analog channels width range 1mV/div~20V/div
2. 7 inches widescreen LCD displays
3. Special Print Scree Feature
4. Supports plug-and-play USB storage device. Communication with and remote control of computer through the USB device
5. USB drive system software upgrade
6. Storage of waveforms setups and interfaces waveforms and setups reproduction
7. Automatic measurement of 28 waveform parameters
8. Unique waveform recording and replay function
9. Multilingual menu displays
Technical specifications:
| Specifications | UTD2052CL | |
| Channels | 2 | |
| Bandwidth | 50MHz | |
| Sample Rate | 500MS/s | |
| Rise Time | ≤7ns | |
| Memory Depth | 25kpts | |
| Waveform Acquisition Rate | ≥2000wfms/s | |
| Vertical Sensitivity | 1mV/div~20V/div | |
| Timebase Range | 5ns/div~50s/div | |
| Storage | Setup, Wave, Bitmap | |
| Trigger Modes | Edge, Pluse, Alternate | |
| Interface | USB OTG | |
| General Characteristics | ||
| Power | 100-240VAC, 40-440Hz | |
| Display | 7 inches 64K Color TFT LCD, 400×240 | |
| Product Color | White and grey | |
| Product Net Weight | 2.2kg | |
| Product Size(W×H×D) | 306mm ×147mm × 122mm | |
| Standard Accessories | Probe×2 (1×,10× switchable), Power Cord, USB Cable, PC Software CD | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 2pcs | |
| Standard Carton Measurement (L×W×H) | 450mm × 420mm × 280mm | |
| Standard Carton Gross Weight | 8.5kg | |
Accessories:
Probe×2 (1×,10× switchable),
Power Cord,
USB Cable,
PC Software CD
From the date of purchase within one year instrument, is a product quality problem free repair replacement, lifetime supply of maintenance and technical services. The instrument has found anomalies or malfunctions please contact us to arrange the most convenient treatment options.
HuaZheng Electric Manufacturing (Baoding) Co.,Ltd is founded in 2008,the supplier of the State Grid in China.It means we are the supplier of the Chinese Government.And our products spread throughout the whole China.
Our main products : Insulation Oil Tester, Cable Fault Locator, High Voltage Generator,transformer tester, relay protection tester,insulation resistance tester,Power Quality Analyzer and so on.
Close to Tianjin port, the transportation is convenient. our customers come from More than 50 countries, like America, England, Bulgaria, Brazil, Chile, Malysia, Vietnam and so on.
What's more, gurantee 1 year,life long maintance .Products through the CE, ISO, IEC certification, quality and reliable, factory price.
Warmly welcome all partners to join us for mutual benefits cooperation.
