EN10216 Alloy pipe 10CrMo910 (1.7380) Material Seamless steel tube
10CrMo910, with increased molybdenum and chromium, provides greater heat and corrosion resistance than 16Mo3 & 13CrMo45.
Again the material is a pressure vessel grade steel for use in elevated temperature service. Masteel supplies 10CrMo910 to fabricators serving the oil and gas industry. The steel has good weldability and is offered under the EN 10028standard.
Chemical Composition of 10CrMo910
|
Grade |
C |
Si |
Mn |
P |
S |
Cr |
Mo |
Ni |
N |
Cu |
|
|
|
|
|
|
|
|
|
|
|
|
|
10CrMo910 |
0.08/0.14 |
0.5 |
0.40/0.80 |
0.02 |
0.01 |
2.00/2.50 |
0.90/1.10 |
– |
0.012 |
0.3 |
|
|
|
|
|
|
|
|
|
|
|
|
Mechanical Properties of 10CrMo910
Thickness |
Yield Strength |
Tensile Strength |
Elongation (A) |
|
|
|
|
mm |
MPa |
MPa |
% |
|
|
|
|
≤16 |
310 |
480/630 |
18 |
|
|
|
|
>16 ≤40 |
300 |
480/630 |
18 |
|
|
|
|
>40 ≤60 |
290 |
480/630 |
18 |
|
|
|
|
>60 ≤100 |
280 |
470/620 |
17 |
|
|
|
|
>100 ≤150 |
265 |
460/610 |
17 |
|
|
|
|
>150 ≤250 |
250 |
450/600 |
17 |
|
|
|
|
Impact energy KV at test temperature
Thickness |
-20°C |
0°C |
+20°C |
|
|
|
|
mm |
J |
J |
J |
|
|
|
|
≤16 |
– |
– |
31 |
|
|
|
|
>16 ≤40 |
|
|
31 |
|
|
|
|
>40 ≤60 |
|
|
31 |
|
|
|
|
>60 ≤100 |
|
|
27 |
|
|
|
|
>100 ≤150 |
|
|
27 |
|
|
|
|
>150 ≤250 |
|
|
27 |
|
|
|
|
Usage of 10CrMo910 seamless steel pipe
10CrMo910 seamless steel pipe is widely used in the hydraulic prop, high-pressure gas cylinders, high-pressure boilers, chemical fertilizer plants, petroleum cracking, car hemi shells, diesel engine, and hydraulic fittings with pipe.
Seamless steel pipe seamless steel pipe in accordance with the purposes divided into structural; conveyance of seamless steel pipe; boiler seamless steel tubes; boiler with high pressure seamless steel; fertilizers, equipment, high pressure seamless steel; exploration of geological brick seamless steel pipe; petroleum brick exploration with seamless steel pipe; petroleum cracking; ship with seamless steel; cold drawn cold rolled precision seamless steel pipe; the various alloy tube.
Product Show:
Liaocheng Kuncheng steel pipe CO., Ltd.
Room A2709 ChuangYe Building,
Liaocheng City,Shandong Province,China
Mobile&Whatsapp:+8613184174934
Tel&Fax:0086-0635-2930669
Wechat:1447334809
QQ:211296894
Send Inquiry to This Supplier
