EN10305 Cold Drawn E335 Precision Hydraulic Steel Tubes
US$ 600 - 800
MOQ: 5 Tons
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Certification:
CE
Thickness:
1.5, 40
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai/tianjin/qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Grade P235TR1 Din St37 (1.0254) Seamless Steel Tube for Pressure PurposesUS$ 658 - 786MOQ: 5 Tons -
Chrome Plated Steel JIS S20C S45C Skiving Honed TubeUS$ 650 - 999MOQ: 25 Tons
-
EN 10216 Hot Rolled P235GH Boiler Tube 1.0345 Seamless Steel TubingUS$ 800 - 1,200MOQ: 25 Tons
-
S45C,SAE1045,C45,CK45 ,ST45 Round Hollow Section Ms Pipe Seamless TubeUS$ 420 - 819MOQ: 2 Tons
-
SA179 Ms Seamless Tube,Ms Precision Pipe for Boiler TubeUS$ 500 - 750MOQ: 5 Tons
Place of Origin
Shandong, China
Certification
CE
Thickness
1.5, 40
Application
Structure Pipe
Surface Treatment
Other
Technique
Cold Rolled
Alloy Or Not
Non-alloy
Outer Diameter
15 - 1219 mm
Secondary Or Not
Non-secondary
Special Pipe
Thick Wall Pipe
Section Shape
Round
Product Description
EN10305 E335 Precision Steel Pipes/Tubes
1.OD:10mm-219mm
2.WT:1.2mm-45mm
3.Good supplier,perfect steel
4. High quality,high precision, favorable price, good after-sale service
| Grade : | E335 | |
| Number: | 1.0060 | |
| Classification: | Non-alloy quality structural steel | |
| Standard: |
|
|
| Equivalent grades: | Go here |
Chemical composition % of steel E335 (1.0060): EN 10025-2-2004
| P | S | N |
| max 0.045 | max 0.045 | max 0.012 |
Mechanical properties of steel E335 (1.0060)
| Nominal thickness (mm): | to 3 | 3 - 100 | 100 - 150 | 150 - 250 |
| Rm - Tensile strength (MPa) flat and long products | 590-770 | 570-710 | 550-710 | 540-710 |
| Nominal thickness (mm): | to 16 | 16 - 40 | 40 - 63 | 63 - 80 | 80 - 100 | 100 - 150 | 150 - 200 |
| ReH - Minimum yield strength (MPa) flat and long products | 335 | 325 | 315 | 305 | 295 | 275 | 265 |
| Nominal thickness (mm): | to 1 | 1 - 1.5 | 1.5 - 2 | 2 - 2.5 | 2.5 - 3 |
| A - Min. elongation Lo = 80 mm (%) parallel, | 8 | 9 | 10 | 11 | 12 |
| Nominal thickness (mm): | 3 - 40 | 40 - 63 | 63 - 100 | 100 - 150 | 150 - 250 |
| A - Min. elongation Lo = 5,65 √ So (%) parallel, | 16 | 15 | 14 | 12 | 11 |
Mechanical properties
| ReH | Minimum yield strength / Mindestwert der oberen Streckgrenze / Limite d elasticite minimale |
| Rm | Tensile strength / Zugfestigkeit / Resistance a la traction |
| A | Minimum elongation / Mindestwert der Bruchdehnung / Allongement minimal |
| J | Notch impact test / Kerbschlagbiegeversuch / Essai de flexion par choc |
