High-strength 1.1191 Material Cold Rolled CK45 Carbon Steel Plate
US$ 500 - 700
MOQ: 25 Tons
Key Specifications
Get Latest Price
Brand Name:
KCGY
Place of Origin:
Shandong, China
Model Number:
0.12-2.0mm*600-1250mm
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao/shanghai/tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Stainless Steel Sheet / Plate AISI 430 Din En Material 1.4016US$ 1,000 - 2,000MOQ: 5 Tons -
ASTM A519 GRADE 4130 ALLOY STEEL CHROMOLY SHEET IN COILUS$ 990 - 1,250MOQ: 20 Tons
-
ASME SA 387 GRADE 5 Class 1 Chrome Moly Alloy Steel PlateUS$ 960 - 1,250MOQ: 20 Tons
-
Hot Rolled Medium Carbon Steel C45 (1.0503) Carbon Steel PlateUS$ 450 - 600MOQ: 5 Tons
-
5 mm Thick Heat Treated A36 Mild Carbon Steel Plate for StructuralUS$ 300 - 600MOQ: 5 Tons
Brand Name
KCGY
Place of Origin
Shandong, China
Model Number
0.12-2.0mm*600-1250mm
Length
Customer's Requirement
Thickness
0.12mm-4.0mm
Type
Steel Coil
Width
Customer's Requirement
Application
Container Plate
Standard
AISI, ASTM, DIN, GB, JIS
Grade
45# S45C 1045 CK45
Special Use
High-strength Steel Plate
Product Description
Data Table for:Carbon steel:Ck45
| Steel grade type | Carbon steel: |
|---|---|
| Standard | |
| Production specifications | Steel plate,Sheet, Coil,Flat bar,Round bar, Strip steel,wire,All kinds of forgings. |
| Mchining | Turning Milling Grinding Deep hole drilling: length max 9.8 meters. |
Range of work |
Round bar steel: 1mm to 2000mm Square-shape steel: 10mm to 1000mm steel Plate/sheet:0.08mm to 800mm Width: 10mm to 1500mm Lenth: We can supply any lenth based on the customer's requirement. Forging: Shafts with flanks/pipes/tubes/slugs/donuts/cubes/other shapes Tubings: OD: φ4-410 mm, with wall thickness ranging from 1-35 mm. |
| Heat treatment | Normalizing,Annealing,Tempering,Quenching,Hardening and tempering,Seasoning,Surface hardening,Carburizing |
Ck45 Chemical composition and Mechanical properties
| C ≤ |
Si ≤ |
Mn ≤ |
P ≤ |
S ≤ |
Cr | Ni |
|---|---|---|---|---|---|---|
| 0.42-0.50 | 0.40 | 0.50-0.80 | 0.030 | 0.035 | ||
| Mo | Al | Cu | Nb | Ti | V | Ce |
| N | Co | Pb | B | Other | ||
| Cr+Ni+Mo ≤ 0.63 |
Mechanical Properties
| Properties | Conditions | ||
|---|---|---|---|
| T (°C) | Treatment | ||
| Density (×1000 kg/m3) | 7.7-8.03 | 25 | |
| Poisson's Ratio | 0.27-0.30 | 25 | |
| Elastic Modulus (GPa) | 190-210 | 25 | |
| Tensile Strength (Mpa) | 1158 | 25 | oil quenched, fine grained, tempered at 425°C |
| Yield Strength (Mpa) | 1034 | ||
| Elongation (%) | 15 | ||
| Reduction in Area (%) | 53 | ||
| Hardness (HB) | 335 | 25 | oil quenched, fine grained, tempered at 425°C |
Thermal Properties
| Properties | Conditions | ||
|---|---|---|---|
| T (°C) | Treatment | ||
| Thermal Conductivity (W/m-K) | 42.7 | 100 | |
| Specific Heat (J/kg-K) | 477 | 50-100 | |
Physical Properties
| Quantity | Value | Unit |
|---|---|---|
| Thermal expansion | 16 - 17 | e-6/K |
| Thermal conductivity | 16 - 16 | W/m.K |
| Specific heat | 500 - 500 | J/kg.K |
| Melting temperature | 1370 - 1400 | °C |
| Service temperature | 0 - 500 | °C |
| Density | 8000 - 8000 | kg/m3 |
| Resistivity | 0.7 - 0.7 | Ohm.mm2/m |
