EN 1.4016 AISI 430 stainless steel sheet
Stainless steel grade 1.4016 is currently the most used ferritic stainless steel grade in the world. This medium chromium steel corresponds to the industry standard of AISI 430. A chromium content of 16 % gives better corrosion resistance and the grade is used in wide range of applications, mostly indoors.
Grade 4016 is a general 16% Cr ferritic stainless steel, feasible for many applications including catering, appliances and indoor applications. Typical applications include washing machine drums, dishwashers, sinks, countertops, and range hoods.
Grade 4016 is typically used with a polished or brushed finish or with a bright finishes like 2BB or bright annealed BA (2R).
Material Properties
Base Metal Price14 % rel
Brinell Hardness160
Calomel Potential-220 mV
Density7.7 g/cm3 (480 lb/ft3)
Elastic (Young's, Tensile) Modulus210 GPa (30 x 106 psi)
Electrical Conductivity2.9 % IACS
Electrical Resistivity Order of Magnitude-6 10x Ω-m
Elongation at Break22 %
Melting Onset (Solidus)1430 °C (2610 °F)
Modulus of Resilience (Unit Resilience)170 kJ/m3
Poisson's Ratio0.28
PREN (Pitting Resistance)17
Specific Heat Capacity460 J/kg-K
Strength to Weight Ratio66 kN-m/kg
Tensile Strength Ultimate (UTS)510 MPa (74 x 103 psi)
Tensile Strength Yield (Proof)270 MPa (39 x 103 psi)
Thermal Conductivity25 W/m-K
Thermal Diffusivity7.1 m2/s
Thermal Expansion10 µm/m-K
Unit Rupture Work (Ultimate Resilience)95 MJ/m3
The length of each bar compares the given value to the highest value in the database.
Alloy Composition
Iron (Fe)79.1 to 84 %
Chromium (Cr)16 to 18 %
Manganese (Mn)0 to 1.0 %
Silicon (Si)0 to 1.0 %
Nickel (Ni)0 to 0.75 %
Carbon (C)0 to 0.12 %
Phosphorus (P)0 to 0.040 %
Sulfur (S) 0 to 0.030 %
