Proximity Access Control Waterproof RFID Card Reader With EM And Hid Card Wiegand Reader
Proximity Access Control Waterproof RFID Card Reader With EM And Hid Card Wiegand Reader
Model No.: S1-RX 125KHz&13.56MHz
/proximity-access-control-waterproof-rfid-card-reader-with-em-and-mifare_p370.html
The S1-RX reader is an advanced 125KHz & 13.56MHz technology proximity reader.
It is attractively designed with a thin profile and modern appearance, and waterproof.
Feature:
> Waterproof conforms to IP66
> Wiegand 26~37 bits input & output
> One relay, 1000 users
> User data can be transferred by Wiegand line
> Access modes: Card, PIN, Card + PIN, Multi Cards
> Pulse mode, toggle mode
> Card type: 125KHz EM & Hid card, PIN length: 4~6 digits
> 2 pcs devices support interlock for two doors
Operating Voltage |
9~24V DC |
Frequency |
125KHz & 13.56MHz |
Card Type |
125KHz - EM & Hid Card |
13.56MHz - Mifare Card (ISO 14443A Compatible) | |
Reading Distance |
7 CM |
Output Format |
Wiegand 26 bits |
(26~37 bits available upon request) | |
Operating Temperature |
-40℃ ~ 60℃ (-40°F ~ 140°F) |
Standby Current |
|
Operating Humidity |
10% ~ 95% RH |
Index of Protection |
IP66 |
Dimensions |
L103 x W48 x H19 (mm) |
Send Inquiry to This Supplier
