KR 200 , Small Volume, Light Weight, Easy to Use Surface Roughness Tester

KR 200 , Small Volume, Light Weight, Easy to Use Surface Roughness Tester thumbnail-1
KR 200 , Small Volume, Light Weight, Easy to Use Surface Roughness Tester thumbnail-2
KR 200 , Small Volume, Light Weight, Easy to Use Surface Roughness Tester thumbnail-3
KR 200 , Small Volume, Light Weight, Easy to Use Surface Roughness Tester thumbnail-4
KR 200 , Small Volume, Light Weight, Easy to Use Surface Roughness Tester thumbnail-5
KR 200 , Small Volume, Light Weight, Easy to Use Surface Roughness Tester photo-1
KR 200 , Small Volume, Light Weight, Easy to Use Surface Roughness Tester photo-2
KR 200 , Small Volume, Light Weight, Easy to Use Surface Roughness Tester photo-3
KR 200 , Small Volume, Light Weight, Easy to Use Surface Roughness Tester photo-4
KR 200 , Small Volume, Light Weight, Easy to Use Surface Roughness Tester photo-5
US$ 900 - 900 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HST
Place of Origin:
Shandong, China
Model Number:
KR200
Contact Supplier Request Quote Chat Now
Jinan Hensgrand Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO BEIJING SHAGNHAI OR AS YOUR REQUEST
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HST
Place of Origin Shandong, China
Model Number KR200

TR200 Surface Roughness Tester

KR 200 , small volume, light weight, easy to use Surface Roughness Tester

 TECHNICAL DATA



14 Testing Parameters

Ra, Rz=Ry(JIS), Rq, Rt=Rmax, Rp, Rv, R3z, R3y, RzJIS, Rsk, Rku, Rsm, Rmr, Rx,

Measuring Range

Ra: 0.005~16.000μm   Rz: 0.02~160.00μm

Sample Length

0.25, 0.80, 2.50mm

Evaluation Length

(1~5)L

Maximum Drive Stroke

17.5mm/0.7inch

Indication Accuracy

0.001μm

Indication Error

±(7~10)%

Variability

<6%

Data Storage

100 groups

Power

Rechargeable Li-battery

Relative Humidity

<90%

Working Temperature

-20°C~40°C

Size

158x63.5x46mm

Weight of Host

0.4kg



 MAIN FEATURE



*Stylish design with plastic shell, inspired by “TRANSFORMERS”;

*Visual waveform display;

*Electromechanical integration design, small volume, light weight, easy to use;

*Using DSP chip to control and data processing, high speed, low power consumption;

*128 x 64 OLED dot matrix display, digital / graphic display; highlight no perspective;

*Intuitive and rich display information, can display all the parameters and graphics;

*Compatible with ISO, DIN, ANSI, JIS national standards;

*Residual quantity icon, prompting the user to charge;

*Continuous working time: more than 20 hours;

*Real-time clock settings and display, convenient data recording and storage;

*With automatic dormancy, automatic shutdown and power saving function;

*Multi-info Display: measurement information, menu prompt, fault and power switch information indicated.

*With PC software, can be connected to a computer and printer;

*Optional different sensor, measuring platform, mini printer, extension rod and other accessories;

*Support OEM Service, high price performance.



 STANDARD DELIVERY



ITEM

QTY

KR220 Host

1 PC

Standard Sensor KS100

1 PC

Standard Calibration Block

1 PC

Bracket for Calibration Block

1 PC

Adjustable Support

1 PC

Power Charger

1 PC

USB Cable

1 PC

PC Software

1 PC

User manual

1 PC

Instrument case

1 PC

Warranty

2 Years









KR 200 , small volume, light weight, easy to use Surface Roughness TesterKR 200 , small volume, light weight, easy to use Surface Roughness TesterKR 200 , small volume, light weight, easy to use Surface Roughness Tester
