HST650  Portable Digital Metal Ultrasonic Flaw Detector



HST-650 Portable Digital Ultrasonic Flaw Detector



Trade:cn1001190896           Skype:henstest            Email: lisa at

Product Description
1. HST650 Ultrasonic Flaw Detector Application
The instrument can be widely used in locating and sizing hidden cracks, voids, disbands, and similar discontinuities in welds, forgings, billets, axles, shafts, tanks and pressure vessels, turbines, and structural components.
2. HST650 Ultrasonic Flaw Detector Features
  • Automated display precise flaw location (Depth d, level p, distance s, amplitude, sz dB);
  • Automated switch three staff gauge ((Depth d, level  p, distance s)
  • Automated calibration of transducer Zero-point, Angles, Front edge and material Velocity
  • Convenient to make and use DACTCG and AVG to evaluate the echo, the curve can be modified and compensated
  • 6dB DAC functions
  • Standards of test for DAC is saved.
  • 500 independence setup, any criterion can be input freely, we can work in the scene without test block
  • Big memory of 1000 A graph
  • Automated gain and gain scan;
  • Peak Hold and Peak Memory;
  • B scan;   AWS D1.1
  • Automated make video of test process and play; use USB flash disk,the length of video is unlimited.
  • Powerful pc software and reports can be export to excel
  • Li battery, continue working time up to 10 hours;
  • The embeded software can be online updated;
Technical Parameters

 3. HST650  Ultrasonic Flaw Detector Specificaiton

Title

Parameter

Title

Parameter

Measuring Range(mm)

0 ~  10000

Measurement Mode

Single,Dual,Thru

Vertical Linearity Error

≤3%

Reject

0~80%

Horizontal Linearity Error

≤0.1%

Pulse Displacement(μs)

-20 ~  +3400

Sensitivity Leavings

≥62dB

Zero(μs)

0.0 ~  99.99

Dynamic range

≥34dB

Port Type

BNC / LEMO

Resolving Power

≥36dB

Operating Temperature  (℃)

-20~50

Frequency Range(MHz)

0.5 ~  15

H×W×D(mm)

240×156×50

Gain(dB)

0 ~  120

Weight(kg)

1.0(with battery)

Material Velocity(m/s)

1000 ~  15000







4. Detailed Tester Pictures

HST-650 Portable Digital Ultrasonic Flaw DetectorHST-650 Portable Digital Ultrasonic Flaw Detector

HST-650 Portable Digital Ultrasonic Flaw Detector
