Help CenterCE Approved HVS-1000A Digital Display Micro Vickers Hardness Tester/Hardness Testing Machine
Related Products
-
HV-1000A Motorized Turret Digital Micro Vickers Hardness Test DeviceUS$ 2,000 - 4,500MOQ: 1 Set -
HB-3000B Digital Brinell Hardness Testing MachineUS$ 999 - 2,999MOQ: 1 Set
-
404SXV Digital Micro Vickers and Knoop Hardness TesterUS$ 999 - 3,999MOQ: 1 Set
-
HVS-1000A Automatic Turret Digital Display Micro Vickers Hardness Tester/Automatic Turret Digital Display DurometerUS$ 2,000 - 10,000MOQ: 1 Set
-
HLN-11A Digital Metal Potable Hardness Tester/Portable Hardness Tester PriceUS$ 500 - 1,000MOQ: 1 Set
Applications:
This tester is a new type of product which is equipped with new features such as RS232 interface, automatic turret, high level LCD display etc. It is especially suited for measuring the Microhardness of thin, small metal test pieces and the brittle materials
Specifications:
Measuring range: 5-3000HV
Test force: 0.09807, 0.2452, 0.4904, 0.9807, 1.961, 2.942, 4.904, 9.807N
(10, 25, 50, 100, 200, 300, 500, 1000gf)
Hardness scale: HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1
Magnifications of the measuring system: 400X (measuring), 100X (observing)
Min. scale value of the optical micrometer: 0.025μm
Measuring range: 200μm
Max. height of test piece: 75mm
Depth of throat: 110mm
Power supply: 220V AC or 110V AC, 50 or 60Hz
Dimensions: 470 x 320 x 500mm
Weight: approx. 50kg
Send an inquiry for this product
Details :
1. Delivery date: 7 days after receiving payment
2. Payment terms: T/T, 100% before shipment.
3. Packages: Plywood Cases
