Microcomputer Servo Fatigue Testing Machine Distributor Price For Tensile Compression Cycle Test
US$ 17,000 - 17,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HST/ Customized
Place of Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
20KN ASTM F2077 Electronic Dynamic Fatigue Testing EquipmentUS$ 19,000 - 19,000MOQ: 1 Set -
Chinese Supplier Dynamic Fatigue Testing MachinesUS$ 20,000 - 26,000MOQ: 1 Set
-
Computer Controlled Electro-hydraulic Servo Torsion Fatigue Testing MachineUS$ 4,500 - 5,000MOQ: 1 Set
-
5kn Computer Controlled Static And Dynamic Electric Fatigue Testing MachineUS$ 4,500 - 5,000MOQ: 1 Set
-
Computer Controlled Electronic Fatigue Testing MachineUS$ 4,500 - 5,000MOQ: 1 Set
Brand Name
HST/ Customized
Place of Origin
China
Fatigue testing machine is mainly used to do the dynamic and static mechanical fatigue test for materials and parts . The machine could also complete the fatigue test of other structural parts with different fixture. The machine also can be
used for materials or structural parts, auto parts and other static mechanical performance test. It is a popular machine for the university, research institutes, enterprises and other experimental equipment to test.
Product Description
Specification
Model |
HST-DP2 |
HST-DP5 |
HST-DP10 |
HST-DP20 |
|||
Max testing force |
±2000N |
±5000N |
±10000N |
±20000N |
|||
Load frame |
Two-column platform type, cross beam electric adjustment |
||||||
Test force measuring range |
Dynamic 2%～100%FS |
||||||
Force accuracy and fluctuation |
1% better than indicated value; amplitude fluctuation is not greater than ± 1% F.S |
||||||
Load display resolution |
1/50000 |
||||||
Test force indication accuracy |
Dynamic ± 1%; static 0.5% |
||||||
Displacement indication accuracy |
Indication accuracy from 1%, within ± 0.5% FS |
||||||
Deformation |
Indication accuracy: 2%~ ± 0.5% |
||||||
Frequency rang |
standard machine 0.1-10HZ |
||||||
Accessories |
Standard :Compression, bend, shear etc.(option) |
||||||
Test waveform: |
sine wave, square wave, triangle wave, ramp wave, etc. |
||||||
