Help CenterDPL1000 Electronic Static Testing and Dynamic Testing Machine Fatigue Testing Machine
Related Products
-
HST HENSGRAND Elastic Cushion Fatigue Testing MachineUS$ 10,000 - 10,000MOQ: 1 Set -
High Precision Microcomputer Control Slow Strain Rate Stress Corrosion Fatigue Testing MachineUS$ 20,000 - 40,000MOQ: 1 Set
-
High Temperature Gas Corrosion Fatigue Testing MachineUS$ 20,000 - 40,000MOQ: 1 Set
-
DIN50100 Gear Wheel /Bolt/Connecting Rod High Frequency Fatigue Testing MachineUS$ 15,000 - 50,000MOQ: 1 Set
-
ASTM F1717-2010 Electronic Fatigue Testing Machine for Spinal Implant ConstructsUS$ 19,000 - 19,000MOQ: 1 Set
Mainly used to do the dynamic and static mechanical fatigue test for materials and parts . The machine could also complete the fatigue test of other structural parts with different fixture. The machine also can be used for materials or structural parts, auto parts and other static mechanical performance test. It is a popular machine for the university, research institutes, enterprises and other experimental equipment to test.
electronic fatigue testing machine
Model |
DPL1000 |
Max. Test force(KN) |
±10 |
Resolution |
0.001mm |
Accuracy |
Better than ±0.5% of reading |
Max. Static test force(kn) |
10(15) |
Max. Dynamic test force(kn) |
±10(15) |
Deformation measuring range |
0.2-100%FN |
Deformation accuracy |
Better than ±1% of reading |
Displacement resolution |
0.001mm |
Frequency (HZ) |
0.001-10 |
Amplitude (mm) |
±75 |
Tensile stroke(mm) |
±75 |
Frame |
Double column |
Distance between columns(mm) |
550 |
Test width(mm) |
450 |
Host dimension(mm) |
1500×550×1700 |
Fixture |
Standard tensile fixture, compression fixture and three-points bending fixture |
Electric control system installation way |
Inhead type |
Tensile fixture tooling | |
Axie Diameter of tooling |
φ30 |
Clamping range(2 pairs) |
0-7(flat jaw) |
|
φ4-φ9 |
|
φ9-φ14 |
Compression fixture tooling | |
Axie Diameter of tooling |
φ30 |
Compression plate diameter |
φ100 |
Three-points bending fixture tooling | |
Axie Diameter of upper tooling |
φ30 |
Height of three-points bending |
45mm |
|
|
|
|
