DWC -80 degree low temperature bath for charpy impact testing
Contact me:Sunny mobile:+86-15866777590 Skype:jessica-hssd
1. Application
The mechine is designed according to Charpy notch Impact Test Method for Metal Material, and adopts compressor cooling technology. It utilizes the heat balance principle and cycle stirring method to realize the constant temperature cooling to impact specimen with the reliable performance. Digital display, automatic control temperature, and it is the ideal equipment for cooling and keeping temperature to impact specime
2.Main Specifications:
Model |
DWC-40 |
DWC-60 |
DWC-80
|
DWC-100 |
Temperature range |
+30~-40° |
+30~-60° |
+30~-80° |
+30~-100° |
Temperature Control Accuracy |
±0.5° |
|||
|
Temperature dropping speed
|
+30°C~0°C 1.2°C/min |
+30°C~0°C 2°C/min |
+30°C~0°C 2°C/min |
+30°C~0°C 2°C/min |
|
0°c~-20°C 0.8°C/min |
0°c~-20°C 1.5°C/min |
0°c~-20°C 1.5°C/min |
0°c~-20°C 1.5°C/min |
|
|
-20°C~-40°C 0.5°C/min |
-20°C~-40°C 1.0°C/min |
-20°C~-60°C 1.0°C/min |
-20°C~-40°C 1.0°C/min |
|
|
-40°C~-60°C 0.7°C/min |
-60°C~-80°C 0.7°C/min |
-60°C~-100°C 0.7°C/min |
||
Cold Room Volume |
150×505×240mm |
|||
Dimensions |
900×505×850 mm
|
900×505×850 mm
|
900×505×850 mm
|
1500×1200×1200 mm
|
Box Material |
Steel Spray |
|||
Loading the number of samples |
>60 |
>60 |
>60 |
>200 |
Mode of refrigeration |
Compressor refrigeration |
|||
Cooling Medium |
Ethanol or other unfrozen liquid |
|||
Power |
7Kw |
7Kw |
7Kw |
7Kw |
3.standards:
ASTM, E23-02a, En10045, ISO83,GB/T229-2009
Welcome to contact Sunny for more informations: Whatsapp/Line/Phone: +8615866777590 Skype:jessica-hssd Email: sunny at
