Home > Products > Electronic Universal Testing Machine > WDW computer control PP woven bags tensile strength testing machine
WDW computer control PP woven bags tensile strength testing machine
- 300 Set / Sets per Month
- Qingdao China
- T/T Credit Card
Product Details
Brand Name: | hensgrand | Place of Origin: | Shandong, China | Model Number: | WDW |
Power: | Electronic |
Product Description
WDW computer control PP woven bags tensile strength testing machine
Main Unit Feature:
1.Adopt single column structure, lower for tensile, upper for compression, double space. The beam is stepless lifting, light but rigid.
2.Adopting ball screw drive, realize no clearance transmission,make sure the precision control of the test force and deformation speed.
3.The photoelectric encoder is the displacement sensor, with high resolution, strong anti-interference ability.
4.The shiel plate with limit mechanism used to control the beam moving range, in order to avoid sensor damaged due to the moving distance is too large.
Main Specifications:
Model | WDW-02 | WDW-05 | WDW-1 | WDW-2 | WDW-3 | WDW-5 |
Max. Load | 0.2 KN 20 kgf 44.8 lbf | 0.5 KN 50 kgf 112 lbf | 1 KN 100 kgf 224 lbf | 2 KN 200 kgf 448 lbf | 3 KN 300 kgf 672 lbf | 5 KN 500 kgf 1120 lbf |
Load Accuracy | ≤±1% | |||||
Load Range | 2%-100% Of Full Scale | |||||
Disp. Resolution | 0.01mm | |||||
Test Speed | 0.05-500mm/min|0.001968-19.685in/min | |||||
Tensile Space | 750mm|30in | |||||
Dimension | 550×350×1580mm | |||||
Power Supply | 220V, 1ph, 0.5KW | |||||
Weight (KG) | 150KG|330lb |
