WDW-100GT 100KN mechanical testing system/ Physical Properties Testing Machine / Instruments
Contact me:Sunny mobile:+86-15866777590 Skype:jessica-hssd
1. Application:
It is applicable for wide range of material for tension, compression, bending, shearing and low cycle test. Suitable for metal, rubber, plastic, spring, textile, and composite materials . It is widely used in the corresponding industries, research and development, test institutes and training centers etc.
2.Standard:
ASTM, ISO, DIN, GB and other international standards.
3.Main Specifications:
Model | WDW -5GT | WDW -10GT | WDW -20GT | WDW -30GT | WDW -50GT | WDW -100GT |
Max. Load | 5kN 500kgf 1120lbf | 10kN 1000kgf 2240lbf | 20kN 2000kgf 4480lbf | 30kN 3000kgf 6720lbf | 50kN 5000kgf 11200lbf | 100kN 10000kgf 22400lbf |
Load accuracy | ≤±1% | |||||
Load range | 0.2%-100% of full scale | |||||
Load resolution | 1/500000 of full scale | |||||
Disp. resolution | 0.01mm | |||||
Test speed | 0.01-500mm/min | 0.01-500mm/min | ||||
Tensile space | 750mm|30in | 650mm|25.6in | 650mm|25.6in | |||
Comp. space | 750mm|30in | 650mm|25.6in | 650mm|25.6in | |||
test width | 450mm | 450mm | 450mm | |||
Dimension | 730×430×1700mm | 755×480×1780mm | 825×600×1950mm | |||
Power supply | 220V, 1ph, 0.5kW | 220V, 1ph, 0.75kW | 220V, 1ph, 1kW | |||
Weight (kg) | 250kg|550lb | 280kg|616lb | 350kg|770lb | |||
