WDW-300E Series Computerized Electronic Universal
Testing Machine/Floor Type
1. Application:
WDW series computerized electronic universal testing machines are designed and
manufactured according to ASTM, ISO, DIN, GB and other international standards.
Applicable for wide range of material for tension, compression, bending, shearing
and low cycle test. Suitable for metal,rubber,plastic,spring,textile and components
testing. It is widely used in the corresponding industries, research and development,
test institutes and training centers etc.
2. Main Specifications:
Model |
WDW-200E |
WDW-300E |
WDW-500E |
WDW-600E |
Max. Load |
200 KN 20000 kgf 44800 lbf |
300 KN 30000 kgf 67200 lbf |
500 KN 50000 kgf 112000 lbf |
600 KN 60000 kgf 134400 lbf |
Load Accuracy |
≤±0.5% |
|||
Load Range |
0.2%-100% Of Full Scale |
|||
Load Resolution |
1/500000 Of Full Scale |
|||
Disp. Resolution |
0.01mm |
|||
Test Speed |
0.01-200mm/min |
|||
Tensile Space |
600mm|21.6in |
|||
Comp. Space |
600mm|21.6in |
|||
Test Width |
600mm |
600mm |
570mm |
570mm |
Grips |
Manual(Hydraulic Grip Optional) |
Hydraulic Grip |
||
Dimension |
1110×750×2560mm |
1110×780×2600mm |
||
Round Specimen |
Φ9-Φ26mm |
Φ9-Φ32mm |
||
Flat Specimen |
0-20mm |
0-20mm |
||
Power Supply |
380V, 3ph, 3KW |
380V, 3ph, 4KW |
||
Weight (KG) |
2100kg|4620lb |
2500kg|5500lb |
||
