Simulation transport test rig
Product Usage:
Simulated transport test rig is the assessment of the actual road conditions capability of the specific load of each item in the laboratory to simulate the impact, vibration, etc. experienced by the car during transportation on the highway to obtain the actual working conditions in the laboratory. The effect of the packaging, packaging, or internal product, thereby providing a basis for the assessment or confirmation of the packaging of the article.
Product features:
Analog broadband random vibration
Acceleration factor adjustable
AC variable frequency control
Heavy-duty channel base with damping rubber, easy to install, strong load, smooth operation
According to the restructuring of similar equipment in Europe and the United States, rotary vibration, in line with European and American transport norms
Technical indicators:
Product name | Simulation transport test rig | ||||||||
Product model | MQ-S2000 | MQ-S3000 | MQ-S4000 | MQ-S6000 | |||||
Maximum load(kg) | 2000 | 3000 | 4000 | 6000 | |||||
Vibration waveform | Broadband random vibration | ||||||||
Simulated speed (km/h) | 20~40 | ||||||||
Simulated road | Third-level intermediate road and fourth-level highway, low-grade road | ||||||||
Time acceleration level | 1:1(Or agreed) | ||||||||
Specimen center height (mm) | <500 | <600 | <700 | <700 | <700 | <700 | <800 | ||
Countertop (mm) | 1500×700 | 1500×700 | 2000×1500 | 2400×1700 | 2700×1800 | 2700×1800 | 4000×2500 | ||
Overall size (mm) | 1920×850×960 | 2550×1920×1400 | 3000×2000×1600 | 4500×2500×2200 | |||||
Table weight | 1600 | 1800 | 5500 | 6000 | 7000 | 7550 | 13000 | ||
power supply | 380VAC ±10% 50Hz | ||||||||
working environment | Ambient temperature: 0 ~ 40 °C, relative humidity: ≤ 80% RH, no strong vibration, electromagnetic radiation, no dust and corrosive substances around; | ||||||||
Note:1.according to the specific requirements of the user non-standard custom; 2.This technical information is subject to change without notice. | |||||||||
| Related Products: |
Click the pictures for detail product info
| Packing & Delivery: |
| About Us: |
Zhongkemeiqi (Tianjin) Technology Co., Ltd, which is a high-tech enterprise specializing in the research, development, production and sales of many kinds’ climatic chambers.
We have passed the ISO9001 quality management, and our team consists of several senior experts who have been engaged in the development, manufacture and maintenance of environmental test equipment for many years.
Temperature and Humidity test chamber,
Rapid Temperature Change test chamber,
Thermal Shock test chamber,
Temperature and Low-Pressure test chamber,
Temperature Humidity and Vibration test chamber;
Ultra-Low Temperature Chamber /Solution,
Aging test chamber (UV, Xenon lamp, Ozone) ,
Rain / Sand Dust test chamber,
Vacuum drying oven, …
| Factory Display: |
| Our Certificates: |
| FAQ: |
Q1: How can i get a quotation?
A1: Kindly provide us your details request (inner chamber size, temperature range, humidity range, power supply, product, etc.), leave us an inquiry or email and we will response promptly!
Q2: What's your temperature & humidity range?
A1: Our standards temperature range is -70℃~+180℃, 20%~98%RH.
We also can do Ultra low temperature to -190℃ .
Q3: What's your rate of heating & cooling?
A3: Our standards rate is average 3℃/min for heating, 2℃/min for cooling.
3℃/min,5℃/min,8℃/min,10℃/min,15℃/min linear or non-linear speed is available for us.
Q4: What's your warranty?
A4: 12 Months (Noted: free spares parts can be offered during warranty period, exclude consumables and man-made damages), life-time technical service
