Heated Incubators
Product Usage:
The product is suitable for the research and industrial production sectors such as medical and health, pharmaceutical industry, biochemistry and agricultural sciences for bacterial culture, fermentation and other constant temperature tests.
Features:
1. Microcomputer intelligent temperature controller
2. Internal and external double door structure, small temperature fluctuations, full use of internal doors
3. Tempered glass door, open the outer door, do not affect the temperature inside the box when viewing the inside of the box
4. The use of high-quality stainless steel liner, semi-circular arc
Technical indicators:
product name | Heated Incubators | ||||
Product number | MQ-DHP-9052 | MQ-DHP-9082 | MQ-DHP-9162 | MQ-DHP-9272 | |
Nominal volume | L | 50 | 80 | 160 | 270 |
Stainless steel mesh | Floor | 2 | 2 | 2 | 2 |
power | watt | 210 | 280 | 380 | 570 |
Inner size | Width × depth × height (mm) | 350×350×410 | 400×400×500 | 500×500×650 | 600×600×750 |
External size | Width × depth × height (mm) | 495×530×720 | 545×580×805 | 645×680×955 | 745×780×1055 |
Performance
| temperature range | RT+5~65℃ | |||
Temperature fluctuation | ±0.5℃ | ||||
Temperature uniformity | ≤±2.0℃ | ||||
The main components
| Control System | Programmable controller + touch screen + independent development program | |||
Heating system | Nickel-chromium alloy heater | ||||
sensor | Class A PT100 platinum resistance | ||||
Circulatory system | High temperature and low noise motor, stainless steel centrifugal impeller | ||||
main material | Carton material | Adopting the domestic first streamlined arc design, the shell is made of cold-rolled steel plate and the surface is electrostatically sprayed | |||
Inner box material | International standard SUS304# stainless steel mirror treatment | ||||
Insulation material | Superfine glass fiber | ||||
Sealing material | Nano material seals | ||||
voltage | AC220V 50Hz | ||||
Timing duration | 0-9999mintues | ||||
safety devices | Leakage, short circuit, motor overheating, heater overheating, multiple overtemperature protection | ||||
Environmental requirements | Ambient temperature: 5~35°C, relative humidity: ≤85%RH, no strong vibration, electromagnetic radiation, no dust and corrosive substances around | ||||
Note: 1, temperature performance parameters are in the ambient temperature of 25 °C, studio no load conditions, in accordance with GB/T5170.2-2008 test; 2, according to the specific requirements of users customized non-standard high-temperature test box; 3. This technical information is subject to change without notice. | |||||
| Related Products: |
Click the pictures for detail product info
| Packing & Delivery: |
| About Us: |
Zhongkemeiqi (Tianjin) Technology Co., Ltd, which is a high-tech enterprise specializing in the research, development, production and sales of many kinds’ climatic chambers.
We have passed the ISO9001 quality management, and our team consists of several senior experts who have been engaged in the development, manufacture and maintenance of environmental test equipment for many years.
Temperature and Humidity test chamber,
Rapid Temperature Change test chamber,
Thermal Shock test chamber,
Temperature and Low-Pressure test chamber,
Temperature Humidity and Vibration test chamber;
Ultra-Low Temperature Chamber /Solution,
Aging test chamber (UV, Xenon lamp, Ozone) ,
Rain / Sand Dust test chamber,
Vacuum drying oven, …
| Factory Display: |
| Our Certificates: |
| FAQ: |
Q1: How can i get a quotation?
A1: Kindly provide us your details request (inner chamber size, temperature range, humidity range, power supply, product, etc.), leave us an inquiry or email and we will response promptly!
Q2: What's your temperature & humidity range?
A1: Our standards temperature range is -70℃~+180℃, 20%~98%RH.
We also can do Ultra low temperature to -190℃ .
Q3: What's your rate of heating & cooling?
A3: Our standards rate is average 3℃/min for heating, 2℃/min for cooling.
3℃/min,5℃/min,8℃/min,10℃/min,15℃/min linear or non-linear speed is available for us.
Q4: What's your warranty?
A4: 12 Months (Noted: free spares parts can be offered during warranty period, exclude consumables and man-made damages), life-time technical service
