Leadshine 2 Phase Stepper Driver MA860C

Features

MA860C stepper drives adopting Leadshine latest advanced stepper control technology. Those stepper drives are highly reliable with good performance and highly competitive cost. MA860C stepper drives feature advanced DSP microstepping and anti-resonance technology for optimized torque, smooth motion, extra low noise, and very low motor heating. The feature of stepper motor auto identification & configuration will allow the driven stepper motors always running at the optimized performance.

MA860C stepper drives are easy to configure and setup. Output current and micro step resolution can be simply set up via DIP switch configuration.
MA860C stepper drives are ideal for step & direction applications requiring step & direction 2 or 4 phase stepper motor control.
·         Step & direction or CW/CCW Control
·         Smooth motion, low motor heating, extra low noise & vibration
·         High reliability and extra low failure rate
·         Anti-resonance
·         Automatic stepper identification and configuration
·         Easy DIP switch configuration & simple setup
·         Idle current reduction



Parameters





Parameters

MA860C

Min

Typical

Max

Unit

Output Current

1.8

-

7.2 (5.1 RMS)

A

Supply Voltage

36VAC

48VAC

80VAC

VAC

50

68

110

VDC

Logic Signal Current

7

10

16

mA

Pulse Input Frequency

0

-

300

kHz

Step Revolution

400



51200

Pulse/Rev

Isolation Resistance

500

MΩ

Suitable Stepper Motors

NEMA 23,34,42

Detailed Images



Drawing

 36-80VAC 1.8-7.2A Leadshine 2 Phase Stepper Driver MA860C
