Help CenterAuto Car Diagnostic CR918S Multi-function Common Rail Injector Pump Test Bench
Related Products
-
Automotive Diagnostic CR918S Common Rail Pump and Injector Test Bench Machine With PT and Coding FunctionUS$ 19,500 - 30,000MOQ: 1 Set -
CR918S pt Pump Test Heui c7 c9 Common Rail Diesel Fuel Injector Pump Test BenchUS$ 20,000 - 20,000MOQ: 1 Set
-
Cr918s Common Rail Comprehensive Test Bench With 6 Injectors Triggered at One TimeUS$ 8,500 - 19,500MOQ: 1 Set
-
ECONOMIC CHOICE BC-CR708 COMMON RAIL INJECTOR TEST BENCH With HEUI EUI EUP FunctionUS$ 4,500 - 8,000MOQ: 1 Set
-
BC-CR718 Diesel Fuel Common Rail Injector Test BenchUS$ 5,900 - 8,000MOQ: 1 Set
6 pcs injectors can be triggered at the same time , and 6 injectors correction codes can be generated simultaneously!
Accurate response time
Generate oil volume correction code
Test PT pump
Test PT injector
Test HPI Q60 X15
Test Cummins HPI Actuator
FEATURES:
Bosch 6,7,8,9,10-digit IMA encoding generation
Bosch piezo injector IMA,ISA encoding generation
DENSO QR oil volume correction code generation
Delphi C2i,C3i encoding generation
Siemens (VDO) ICC code generation
►Test common rail injector
►Test common rail pump
►Test EUI/EUP
►Test the HEUI injector
►Test HEUI actuation pump
►The highest rail pressure is 2600 bar
►Drive motor 22KW
►Injection drive and system voltage monitor
►Common rail with filter function
►Dual DRV configuration
►High pressure filter plugging reminder function
►Waste tank overflow warning
►Oil tank and diesel tank strong integrated air conditioning system
TECHNICAL PARAMETERS
Main power |
380V AC 220V(Optional) |
Phase |
Three,single(Optional) |
Frequency |
50HZ/60HZ |
Current |
45A(MAX) |
Main Motor |
22kw |
Main motor rotation |
0-4000 RPM/MIN |
Oil motor HP/FLOW |
0.19KW/13L/MIN |
Diesel motor HP/FLOW |
0.19KW/13L/MIN |
Control circuit voltage |
DC12V/24V 350W |
ECU internal voltage |
0-200V DC(MAX) |
Oil tank volume |
30L |
Diesel Tank volume |
52L |
Tempreature control |
Heating/Forced cooling |
Max rail pressure |
180Mpa 240Mpa(Optional) |
Flowmeter(injection) |
4-550ml/min |
Flowmeter(pump supply) |
1-400L/H |
Flowmeter(pump flowback) |
1-400L/H |
Flowmeter(oil) |
5-600L/H |
Center distance between motor and working bench |
125mm |
Weight |
1100KG |
Outlook size net |
(LxWxH)2400x1350x1880 |
Wooden cage |
(LxWxH)2500x1480x2050 |
Pls point the model number , you will see more details:
8 cylinder 12psm test bench |
EPS100 CR injector test bench |
EPT2000 cummins injector test bench |
cr825 multi-function test bench |
LGC4000 test bench with computer control |
CRS-1000 CR injector tester |
LGC816 CR injector pump test bench |
LGC-CR918 test bench |
PQ1000 CR injector tester |
PT212 cummins pump test bench |
crs709 CR injector pump test bench |
crm-100 3 stage tools |
LGC-D3 turbochager balancing machine |
vp37 pump tester |
vp44 pump tester |
EUI EUP CAMBOX |
12 cylinder 12psb diesel test bench |
EPS200 cr injector test bench |
crs4000 diesel test bench |
cr318 heui ,CR injector test bench |
1.Q:How can i start the order?
A:STEP1,please let us know what model do you interest and quantity you need;
STEP2,then we will make a PI for you to confirm all the order detail;
STEP3,after you confirmed all the detail,then you can arrange the payment;
STEP4,after we received the payment we will start the production and delivery for you.
2.Q:What is the delivery time?
A:It depend on what kind of product do you need,if you need a small tester or the spare parts,
about 2-3 work days
For big product such as test bench or balancing machine takes about 7-10 work days.
3.Q:What is the payment term?
A:We support TT/ WEST UNION/LC/ MONEY GRAM / ALIBABA TRADE ASSURANCE.
4.Q: what is your after sale service?
A: One year warranty for our product, whole life technical support whole-life.
5.Q:What delivery term do you support?
A:For sea shipping,we can do the term EXW,FOB,CFR,CIF,DDU and DDP.
For courier service,we can delivery by DHL TNT,FEDEX,EMS and etc....
Please for more information directly contact us we will give you the best option.
