Help CenterXY-130 Core Samplling Drilling Machine 130 Meters Depth Drill Hole Machine
Related Products
-
HBZ-1 Double Head Crawler Environmental Sampling Soil Tamping Core Drilling RigUS$ 12000 - 14000MOQ: 1 Set -
HBZ-2 Soil Sampling Drilling Rig Caterpillar Hydraulic Pressure Drilling MachineUS$ 12000 - 14000MOQ: 1 Set
-
Crawler Type Soil Sampling Drilling Machine Can Take Soil Sand Core SampleUS$ 7900 - 8900MOQ: 1 Set
-
JZ-C Tractor Truck Type Water Well Drilling Machine Large DiameterUS$ 9500 - 9800MOQ: 1 Set
-
BXZ-1L Easy Operation Portable Backpack Diamond Rock Core Drilling Rig For SaleUS$ 4500 - 5000MOQ: 1 Set
Keywords: hydraulic water drilling machine price, water borehole drilling machine
1. The applications of XY-130 drilling machine
Water well,field irrigation well, engineering water well, precipitation well and so on; geological survey, geophysical exploration, road and high-rise building foundation exploration, wells, blasting holes and other drilling projects.
2. The Specifications of XY-130 drilling machine
Maximum opening hole diameter |
400mm |
Drilling depth |
130m |
End hole diameter |
75mm |
Drilling angel |
90-75° |
Dimension |
2.75X0.95X1.60m |
Drilling pipe diameter |
50mm |
Weight without power |
760kg |
Spindle | |
Spindle rotation speed |
71/142/310/20r/min |
Spindle stroke |
450mm |
Winch | |
Maximum lifting weight (single rope) |
2008kb |
Lifting speed |
17/35/75/160rm/s |
Wire-rope diameter: |
13mm |
Roll capacity |
35mm |
Mud pump | |
Type: horizontal single cylinder double action |
flow：180L/min |
Maximum pressure |
1.5mpa |
Working pressure |
0.7mpa |
Inlet pipe diameter |
50mm |
Outlet pipe diameter |
45mm |
Power | |
Diesel |
20hp |
Rated speed |
2200r/min |
Electric motor |
15kw |
Rated speed |
1460r/min |
