LX-2XL Design Output Rate: 1400/bph(5L)

Name: LX-2XL Design Output Rate: 1400/bph(5L)
Brand: Longsun
SKU: 163944085
Availability: InStock

US$ 90000 - 200000 MOQ: 1 Set

Key Specifications

Brand Name:

Longsun

Place of Origin:

China

Model Number:

LX-2XL

Dongguan Longsun Machinery Co.,LTD.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Brand Name Longsun

Place of Origin China

Model Number LX-2XL

Accurate preform-divided

l Servo driven equidistance preform-divided, safe, fast and precise

Traditional mold-Clamping

l The machine adopts one single cylinder to drive the crank to control the clamping system structure.

l The swelling mold and big joint line problems can be solved with the effect of pressurized steel plates.

Safety mold framework structure

l Adopts drawer type structure, mold change and installation are more safe and time-saving with special auxiliary tools

Intelligent operation system

l Human-machine interface control system, high automation, easy operation and safe

Standardized spare parts

l High-quality standardized spare parts guarantee the reliable and stability of the machines

	Item	LX－2XL
Main machine	Maximum bottle capacity	6L
	Maximum output rate(bph)	1,400
	Maximum bottle diameter	Φ180mm
	Neck diameter	Φ25-45mm
	Maximum bottle height under neck	350mm
	Maximum preform height under neck	200mm
	Number of molds	2
Heating part	Number of heating modules	2
	Number of heating lamps	10
	Heating base	56
Air source	Low pressure	1Mpa
	Low pressure air consumption	2m³/min
	High pressure	3.5Mpa
	High pressure air consumption	3m³/min
Weight	G.W.	Around 4000kg
Dimension	Main machine(L×W×H)	3100×1920×2300mm
	Preform unscrambler(L×W×H)	2500×2500×2800mm
