Product Name :Acid Disinfectant of hypochlorous acid
Sterilization Principle:
Under the contain acid environment(PH:2.0-3.0) and the condition of high redox potential, (ORP≥1100MV) The sterilization of Acid Redox Potential is mainly related with trace effective chlorine (5.0-7.0mg/L).H2O2 and nascent oxygen also play bactericidal role .Through destroying living environment of microorganism, Acid Oxidation Potential Water can change potential of cell membrane to enhance permeability of cell membrane , and cell will be swollen and disintegrated,
The metabolizing enzyme in cell and The Nucleic Acid will be destroyed ,after then the Acid Redox Potential Water can eliminate microorganism quickly with the effects of strong oxidability and sterilization.
Function Feature:
Wide Sterilization: The various normal bacteria virus can be eliminated immediately in 10 seconds,and it is hard to produce drug-fast virus.
Efficient Fast: Hepatitis B Surface Antigen can be destroyed in 20 minutes and eliminate spore.
Convenience: A large number of products can be produced and used on-site.
Friendly Environment: It can be reduced to common water after sterilization ,no-no pollution.
Low Cost: The Raw Materials are Pure Water and electrolyzer.
System Feature:
It can be with Printer that can print the related parameter at any time for trace
5” touch screen for operation system
PH,ORP effective chlorine current data and various states are displayed real time .
Automatic washing and salt dissolving system for electrolyzer
Automatically start and stop machinery and monitor the raw water quality.
The box of acid & alkali automatically start without water ,full water automatic standby .
The Supply water with constant pressure meet requirement of peak water .
Automatically remind for no electrolyzer ,overcurrent and voltage protection.
Core Configuration :
The Electrolytic Cell adopt imported ionic membrane
Precision Dosing Pump
Imported Control Chip
Pipeline & Joints of Resistant acid &alkali
Imported Solenoid Valve with Resistant acid & alkali
Medical Grade Water Pump with Resistant Acid &Alkali
Medical Grade Power Filter
Medical Grade Switch Power Supply
Remote Monitoring System
Technical Parameter:
Application Scope: Laboratory ,Research Institutions, Hospital,etc .
| Type & Spec. | CY-CDSP-60/90/120/150/180/200/250/300/350/400/450/500/1000L | |||||
| Inlet Quality | Pure Water ,Conductivity ≤15us/cm,Water Pressure:0.1-0.5Mpa | |||||
| Physicochemical Indexes |
PH:2.0-3.0,ORP≥1100MV,The Effective Chlorine(50-70mg/L), Residual Cl≤1000mg/L |
|||||
| Storage Water Tank | Built-in | Built-out | ||||
| Acid Water Production | 60L/H | 90L/H | 120L/H | 150L/H | 180L/H | 1000L/H |
| Alkali Water Production | 60L/H | 90L/H | 120L/H | 150L/H | 180L/H | 1000L/H |
| Power | 700VA | 900VA | 950VA | 1050VA | 1100VA | 2000VA |
| Weight | 80KG | 80KG | 90KG | 95KG | 100KG | 180KG |
| Outside Size | 532 * 460* 1380MM | |||||
| Power Supply | 220V50HZ | Electrolysis Mode | Continuous Electrolysis | Normal Life of Electrode≥3000 hours | ||
Note:
The requirement of installation & use environment: the temperature 5-40℃,Humidity ≤80%.
There is no direct sunlight in the equipment room,floor drain is set on the ground and drainage is smooth.
Ensure the ground bearing capacity of the equipment room meets the equipment requirements.
-
The raw water can be tap water ,It is better to pure water.
