Cheap Price AC 50Hz 3 Phase Diesel Power 100kw Silent Diesel Generator

Name: Cheap Price AC 50Hz 3 Phase Diesel Power 100kw Silent Diesel Generator
Brand: weichai
Availability: InStock

FOB Price

US$ 1,670 - 5,000 / Set

1 Set(Min. Order)

Port Tianjin /Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	weichai	Place of Origin	Shandong, China
Model Number	40kw 50kw 60kw 80kw 100kw	Rated Current	Depend
Speed	1500/1800rpm	Frequency	50/60HZ
Rated Voltage	400/230V

Product Description

Technical parameters of diesel generator sets:
Genset Technical data
Genset Model	GF-22C TO GF-8700C
Prime Power	10KW to 8700KW
Rated Voltage	400/230V(voltage can be customized)
Frequency	50/60Hz
Diesel generator type	open,silent,soundproof,trailer,container
Color	Customized
ATS	Optional
Controller	Deepsea/Smartgen
Warranty	1year/1500hours
Certificate	ISO9001,CE,ISO14001
Diesel Engine
Brand	With Cummins Weichai Deutz Perkins SEDC Ricardo and so on
Rotating Speed	1500/1800RPM
Speed Governor	Electrical /Mechanical
Cooling System/Type	Water-cooled/Naturally/Turbocharged Inter-cooling
Alternator
Brand	Stamford/Leroy Somer/Marathon/Mecc Alte/Xingnuo...
Phase No.&Connecting Type	Three Phase and Four Lines 3P4W,Y Style Connection
Grading Protection	IP22
Exciter Type	Brushless (AVR automatic voltage regulating)
Insulation Class	H degree
The components of the genset
(1) Diesel Engine; (2)Alternator; (3) Control Panel (4) Accessories
The control panel is Quadruplication protection control panel, with the display of frequency table/water temperature/schedule/battery voltmeter. The genset with low oil pressure, high water temperature, over speed emergency, stop and other pre-protection.

Open Silent Trailer Type

Product Sheetdata

More Details Information Please Contact Us

Diesel Engines for Wechai Shangchai (SDEC) Yuchai Deutz Ricardo Lovol Cumminss...and so on

Genset with cummins engine+Stamford Alternator(50Hz,1500Rpm)

Genset Model	With Cummins engine model	Alternator Model	Gensets Power Standby Power		Gensets Power Rated Power		Engine Power
Genset Model	Engine	Stamford	kva	kw	kva	kw	Kw/Kva
GF-22C	4B3.9-G2	PI144D	22	18	20	16	24kw/30kva
GF-28C	4B3.9-G2	PI144E	28	22	25	20	24kw/30kva
GF-30C	4B3.9-G2	PI144F	30	24	27	22	24kw/30kva
GF-33C	4BT3.9-G2	PI144G	33	26	30	24	36kw/40kva
GF-39C	4BT3.9-G2	PI144H	39	31	35	28	36kw/40kva
GF-44C	4BT3.9-G2	PI144J	44	35	40	32	36kw/40kva
GF-47C	4BTA3.9-G2	PI144K	47	37	43	34	50kw/62.5kva
GF-55C	4BTA3.9-G2	UCI224D	55	44	50	40	50kw/62.5kva
GF-62C	4BTA3.9-G2	UCI224E	62	50	56	45	50kw/62.5kva
GF-80C	6BT5.9-G2	UCI224F	80	64	73	58	87kw/109kva
GF-94C	6BT5.9-G2	UCI224G	94	75	85	68	87kw/109kva
GF-103C	6BT5.9-G2	UCI274C	103	83	94	75	87kw/109kva
GF-110C	6BTA5.9-G2	UCI274C	110	88	100	80	110kw/135kva
GF-124C	6BTA5.9-G2	UCI274D	124	99	113	90	110kw/135kva
GF-138C	6BTAA5.9-G2	UCI274E	138	110	125	100	120kw/150kva
GF-154C	6CTA8.3-G2	UCI274E	154	123	140	112	163kw/204kva
GF-176C	6CTA8.3-G2	UCI274F	176	141	160	128	163kw/204kva
GF-200C	6CTA8.3-G2	UCI274G	200	160	182	146	163kw/204kva
GF-220C	6CTAA8.3-G2	UCI274H	220	176	200	160	200kw/250kva
GF-253C	6LTAA8.9-G2	UCDI274J	253	202	230	184	235kw/294kva
GF-275C	6LTAA8.9-G2	UCDI274K	275	220	250	200	220kw/240kva
GF-275C1	NT855-GA	UCDI274K	275	220	250	200	231kw/289kva
GF-313C	NTA855-G1A	HCI444D	313	250	275	220	261kw/326kva
GF-330C	NTA855-G1B	HCI444D	330	264	300	240	284kw/355kva
GF-344C	NTA855-G1B	HCI444ES	344	275	313	250	284kw/355kva
GF-378C	NTA855-G2A	HCI444E	378	303	344	275	313kw/391kva
GF-385C	NTA855-G4	HCI444E	385	308	350	280	317kw/391kva
GF-413C	NTA855-G7	HCI444FS	413	330	375	300	343kw429kva
GF-440C	NTA855-G7A	HCI444F	440	352	400	320	360kw/450kva
GF-440C1	KTA19-G2	HCI444F	440	352	400	320	336kw/420kva
GF-495C	KTA19-G3	HCI 544C	495	396	450	360	403kw/504kva
GF-550C	KTA19-G4	HCI544D	550	440	500	400	448kw/560kva
GF-578C	KTA19-G5	HCI544E	578	462	525	420	470kw/588kva
GF-649C	KTA19-G8	HCI544E	649	519	590	472	510kw/640kva
GF-633C	KTAA19-G6	HCI544E	633	506	575	460	520kw/650kva
GF-660C	KTAA19-G6A	HCI544E	660	528	600	480	540kw/675kva
GF-688C	KTAA19-G6A	HCI544F	688	550	625	500	540kw/675kva

Genset Features

B and F series product
1. Original European Technology, Independent R and D.
2. Gen-sets Power Matching Coefficient.
3. Matched with Professional High-temperature Radiator.
4. Professional Application and Integration Capabilities.
5. Option Automation, Auto-switch, Auto-parallel Connection and other Functions Freely.
6. Key Components of The Controller, Circuit Breakers, Generators for the Domestic and International Famous
7.Strong power,high reliability

8.Diesel Engines for Wechai Shangchai (SDEC) Yuchai Deutz Cumminss

weichai deutz 3 phase 24KW 30kva silent diesel generator

high quality 400kw Generator 500kva diesel generator price

weichai deutz 100KW 125Kva diesel generator

low price 125kva soundproof diesel generator 100kw powered by engine 6BT5.9-G2

Our Advantages

10 years experience

With over 10 years of experience in this industry

OEM&ODM

According to customer requirements and products, ODM/OEM services to customers around the world.

Quality assurance

Product quality assurance, with a product license, to provide the perfect after-sales service.

service team

Professional service team and professional technical team.
