High Quality 20kw Silent Diesel Generator

Shenzhen Eshare Trading Co., Ltd.
High Quality 20kw Silent Diesel Generator thumbnail-1
High Quality 20kw Silent Diesel Generator thumbnail-2
High Quality 20kw Silent Diesel Generator thumbnail-3
High Quality 20kw Silent Diesel Generator thumbnail-4
High Quality 20kw Silent Diesel Generator thumbnail-5
High Quality 20kw Silent Diesel Generator thumbnail-6
High Quality 20kw Silent Diesel Generator photo-1
High Quality 20kw Silent Diesel Generator photo-2
High Quality 20kw Silent Diesel Generator photo-3
High Quality 20kw Silent Diesel Generator photo-4
High Quality 20kw Silent Diesel Generator photo-5
High Quality 20kw Silent Diesel Generator photo-6
US$ 1,670 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
weichai
Place of Origin:
Shandong, China
Model Number:
20kw 30kw 40kw 50kw 60kw 80kw 100kw 150kw 200kw 250kw 300kw 350kw 400k
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin /Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name weichai
Place of Origin Shandong, China
Model Number 20kw 30kw 40kw 50kw 60kw 80kw 100kw 150kw 200kw 250kw 300kw 350kw 400k
Rated Current Depend
Speed 1500/1800rpm
Frequency 50/60HZ
Rated Voltage 400/230V
Product Description

Technical parameters of diesel generator sets:
Genset Technical data
Genset ModelGF-22C TO GF-8700C
 Prime Power 10KW to 8700KW
Rated Voltage400/230V(voltage can be customized)
Frequency50/60Hz
Diesel generator typeopen,silent,soundproof,trailer,container
ColorCustomized
ATS Optional
Controller Deepsea/Smartgen
Warranty 1year/1500hours
CertificateISO9001,CE,ISO14001
Diesel Engine
BrandWith Cummins Weichai Deutz Perkins SEDC Ricardo and so on
Rotating Speed1500/1800RPM
Speed GovernorElectrical /Mechanical
Cooling System/TypeWater-cooled/Naturally/Turbocharged Inter-cooling
Alternator
BrandStamford/Leroy Somer/Marathon/Mecc Alte/Xingnuo...
Phase No.&Connecting TypeThree Phase and Four Lines 3P4W,Y Style Connection
Grading ProtectionIP22
Exciter TypeBrushless (AVR automatic voltage regulating)
Insulation ClassH degree
The components of the genset
(1)  Diesel Engine;        (2)Alternator;     (3) Control Panel  (4) Accessories

The control panel is Quadruplication protection control panel, with the display of frequency table/water temperature/schedule/battery voltmeter. The genset with low oil pressure, high water temperature, over speed emergency, stop and other pre-protection.

Open Silent Trailer Type
High quality 20kw silent diesel generator
High quality 20kw silent diesel generator
High quality 20kw silent diesel generator
Product Sheetdata

More Details Information Please Contact Us

Diesel Engines for Wechai Shangchai (SDEC) Yuchai Deutz Ricardo Lovol Cumminss...and so on

Genset with cummins engine+Stamford Alternator(50Hz,1500Rpm)

Genset
Model		With Cummins engine modelAlternator ModelGensets Power
Standby Power		Gensets Power
Rated Power		Engine Power
EngineStamfordkvakwkvakwKw/Kva
GF-22C4B3.9-G2PI144D2218201624kw/30kva
GF-28C4B3.9-G2PI144E2822252024kw/30kva
GF-30C4B3.9-G2PI144F3024272224kw/30kva
GF-33C4BT3.9-G2PI144G3326302436kw/40kva
GF-39C4BT3.9-G2PI144H3931352836kw/40kva
GF-44C4BT3.9-G2PI144J4435403236kw/40kva
GF-47C4BTA3.9-G2PI144K4737433450kw/62.5kva
GF-55C4BTA3.9-G2UCI224D5544504050kw/62.5kva
GF-62C4BTA3.9-G2UCI224E6250564550kw/62.5kva
GF-80C6BT5.9-G2UCI224F8064735887kw/109kva
GF-94C6BT5.9-G2UCI224G9475856887kw/109kva
GF-103C6BT5.9-G2UCI274C10383947587kw/109kva
GF-110C6BTA5.9-G2UCI274C1108810080110kw/135kva
GF-124C6BTA5.9-G2UCI274D1249911390110kw/135kva
GF-138C6BTAA5.9-G2UCI274E138110125100120kw/150kva
GF-154C6CTA8.3-G2UCI274E154123140112163kw/204kva
GF-176C6CTA8.3-G2UCI274F176141160128163kw/204kva
GF-200C6CTA8.3-G2UCI274G200160182146163kw/204kva
GF-220C6CTAA8.3-G2UCI274H220176200160200kw/250kva
GF-253C6LTAA8.9-G2UCDI274J253202230184235kw/294kva
GF-275C6LTAA8.9-G2UCDI274K275220250200220kw/240kva
GF-275C1NT855-GAUCDI274K275220250200231kw/289kva
GF-313CNTA855-G1AHCI444D313250275220261kw/326kva
GF-330CNTA855-G1BHCI444D330264300240284kw/355kva
GF-344CNTA855-G1BHCI444ES344275313250284kw/355kva
GF-378CNTA855-G2AHCI444E378303344275313kw/391kva
GF-385CNTA855-G4HCI444E385308350280317kw/391kva
GF-413CNTA855-G7HCI444FS413330375300343kw429kva
GF-440CNTA855-G7AHCI444F440352400320360kw/450kva
GF-440C1KTA19-G2HCI444F440352400320336kw/420kva
GF-495CKTA19-G3HCI 544C495396450360403kw/504kva
GF-550CKTA19-G4HCI544D550440500400448kw/560kva
GF-578CKTA19-G5HCI544E578462525420470kw/588kva
GF-649CKTA19-G8HCI544E649519590472510kw/640kva
GF-633CKTAA19-G6HCI544E633506575460520kw/650kva
GF-660CKTAA19-G6AHCI544E660528600480540kw/675kva
GF-688CKTAA19-G6AHCI544F688550625500540kw/675kva
Genset Features

B and F series product
1. Original European Technology, Independent R and D.
2. Gen-sets Power Matching Coefficient.
3. Matched with Professional High-temperature Radiator.
4. Professional Application and Integration Capabilities.
5. Option Automation, Auto-switch, Auto-parallel Connection and other Functions Freely.
6. Key Components of The Controller, Circuit Breakers, Generators for the Domestic and International Famous
7.Strong power,high reliability

8.Diesel Engines for Wechai Shangchai (SDEC) Yuchai Deutz Cumminss

High quality 20kw silent diesel generator
High quality 20kw silent diesel generator
High quality 20kw silent diesel generator
High quality 20kw silent diesel generator
High quality 20kw silent diesel generator
High quality 20kw silent diesel generator
