RE4510 UUCC0P5 China Cross Roller Bearing Factory 45x70x10mm

RE4510UUCCO Crossed Roller Bearings (45x70x10mm) Precision Robotic arm use
Crossed Roller Bearings Parameters
Model number- RE4510UUCCO
Inner ring(mm)- 45
Outer ring(mm)- 70
Width(mm)- 10
Weight(Kg)- 0.17
Materials- GCR15/GCR15SiMn
Precision grade- P5/P4/P2
Lubrication type- Grease lubrication Rotating part- Outer Ring Rotation
Load direction- Multi-load
Structure- Separable Inner Ring

Series Model No.

RE2008UUCCO, RE2508UUCCO, RE3010UUCCO, RE3510UUCCO, RE4010UUCCO, RE4510UUCCO, RE5013UUCCO, RE6013UUCCO, RE7013UUCCO, RE8016UUCCO, RE9016UUCCO, RE10016UUCCO, RE10020UUCCO, RE11012UUCCO, RE11015UUCCO, RE11020UUCCO, RE12016UUCCO, RE12025UUCCO, RE13015UUCCO, RE13025UUCCO, RE14016UUCCO, RE14025UUCCO, RE15013UUCO,RE15025UUCCO, RE15030UUCO,RE16025UUCCO, RE17020UUCCO, RE18025UUCCO, RE19025UUCO,RE20025UUCCO, RE20030UUCCO, RE20035UUCCO, RE22025UUCCO, RE24025UUCO,RE25025UUCCO, RE25030UUCCO, RE25040UUCO,RE30025UUCO,RE30035UUCCO, RE30040UUCCO, RE35020UUCCO, RE40035UUCCO, RE40040UUCCO, RE45025UUCCO RE50025UUCCO, RE50040UUCCO, RE50050UUCCO, RE60040UUCO

RE series structure

Due to the X arrangement of the rolling elements, these bearings can support axial forces from both directions as well as radial forces, tilting moment loads and any combination of loads with a single bearing position. This allows designs with two bearing positions to be reduced to a single bearing position. Crossed roller bearings are very rigid, have high running accuracy and are supplied with normal clearance, little clearance or preload. The bearing outer rings can be easily located in the adjacent construction by means of clamping rings.

Application:
