RA20013UUCC0P4 Robot Crossed Roller Bearing Price200x226x13mm
- T/T
- 7 days
You May Like
-
RA19013UUCC0P4 Precision Crossed Cylindrical Roller Slewing Bearings 190x216x13mm
-
RA11008UUCC0P4 ra Series Crossed Cylindrical Roller Bearing Price 110x126x8mm
-
CRBH14025 A UUCCO Slewing Ring Bearing Price Made in China 140x200x25mm
-
CRBH10020A UUCCO CRBH Series Crossed Cylindrical Roller Bearing Manufacturers China90x130x16mm
-
CRBH9016 A UUCCO Crossed Roller Bearings Manufacturers China 90x130x16mm
-
XR496051 xr Series Crossed Tapered Roller Bearings Manufacturers China 203.2x279.4x31.75mm
Product Details
| Brand Name | ZLYQX | Place of Origin | China | |
| Model Number | RA20013UUCC0P4 | Precision Rating | P5 / P4 / P2 | |
| Outside Diameter | 226, | Bore Size | 200, |
Product Description
RA20013UUCC0P4 Cross Roller Bearing / High Precision thin section Cross Roller Bearing
Bearing Model No.: RA20013
Type: Cross Roller Bearing
Size: 200x226x13mm
(Inner Diameter)d: 200mm
(Outer Diameter) D: 226mm
(Thickness / Width) B: 13mm
Series Models
RA5008UUCCO, RA6008UUCCO, RA7008UUCCO, RA8008UUCCO ,RA9008UUCCO, RA10008UUCCO, RA11008UUCCO, RA12008UUCCO, RA13008UUCCO, RA14008UUCCO, RA15008UUCCO, RA16013UUCCO, RA17013UUCCO, RA18013UUCCO, RA19013UUCCO, RA20013UUCCO
RA-C series
RA5008CUUCCO, RA6008CUUCCO, RA7008CUUCCO, RA8008CUUCCO, RA9008CUUCCO, RA10008CUUCCO
shaft diameter
| Identification number | Main dimensious | shoulder height | Basic load rating (radial) | weight | |||||||||
| Inner diameter | outer diameter | Roller pitch circle diameter | width | Greasing hole | r | ds | Dh | C | Co | Kg | ||||
| a | b | |||||||||||||
| d | D | DP | B/B1 | KN | KN | |||||||||
| 50 | RA 5008 | 50 | 66 | 57 | 8 | 2 | 0.8 | 0.8 | 53.5 | 60.5 | 5.1 | 7.19 | 0.08 | |
| 60 | RA 6008 | 60 | 76 | 67 | 8 | 2 | 0.8 | 0.8 | 63.5 | 70.5 | 5.68 | 8.68 | 0.09 | |
| 70 | RA 7008 | 70 | 86 | 77 | 8 | 2 | 0.8 | 0.8 | 73.5 | 80.5 | 5.98 | 9.8 | 0.1 | |
| 80 | RA 8008 | 80 | 96 | 87 | 8 | 2 | 0.8 | 0.8 | 83.5 | 90.5 | 6.37 | 11.3 | 0.11 | |
| 90 | RA 9008 | 90 | 106 | 97 | 8 | 2 | 0.8 | 0.8 | 93.5 | 100.5 | 6.76 | 12.4 | 0.12 | |
| 100 | RA 10008 | 100 | 116 | 107 | 8 | 2 | 0.8 | 0.8 | 103.5 | 110.5 | 7.15 | 13.9 | 0.15 | |
| 110 | RA 11008 | 110 | 126 | 117 | 8 | 2 | 0.8 | 0.8 | 113.5 | 120.5 | 7.45 | 15 | 0.16 | |
| 120 | RA 12008 | 120 | 136 | 127 | 8 | 2 | 0.8 | 0.8 | 123.5 | 130.5 | 7.84 | 16.5 | 0.17 | |
| 130 | RA 13008 | 130 | 146 | 137 | 8 | 2 | 0.8 | 0.8 | 133.5 | 140.5 | 7.94 | 17.6 | 0.18 | |
| 140 | RA 14008 | 140 | 156 | 147 | 8 | 2 | 0.8 | 0.8 | 143.5 | 150.5 | 8.33 | 19.1 | 0.19 | |
| 150 | RA 15008 | 150 | 166 | 157 | 8 | 2 | 0.8 | 0.8 | 153.5 | 160.5 | 8.82 | 20.6 | 0.2 | |
| 160 | RA 16013 | 160 | 186 | 172 | 13 | 2.5 | 1.6 | 1.2 | 165 | 179 | 23.3 | 44.9 | 0.59 | |
| 170 | RA 17013 | 170 | 196 | 182 | 13 | 2.5 | 1.6 | 1.2 | 175 | 189 | 23.5 | 46.5 | 0.64 | |
| 180 | RA 18013 | 180 | 206 | 192 | 13 | 2.5 | 1.6 | 1.2 | 185 | 199 | 24.5 | 49.8 | 0.68 | |
| 190 | RA 19013 | 190 | 216 | 202 | 13 | 2.5 | 1.6 | 1.2 | 195 | 209 | 24.9 | 51.5 | 0.69 | |
| 200 | RA 20013 | 200 | 226 | 212 | 13 | 2.5 | 1.6 | 1.2 | 205 | 219 | 25.8 | 54.7 | 0.71 | |
Drawings and other parameters ,pls contact us free, thanks
