70 PVC wire and cable extrusion line for OD1.5-8.0mm wire
Application:
Suitable for PVC and PE etc. plastic extrusion, mainly used for power wire, computer wire, insulated wire sheath, building wire etc. production.
Equipment constitute: It is composed of double spools pay-off (Japanese style), straightening machine, mainframe, main control cabinet, water trough, accumulator, caterpillar, linkage wire cutting machine, etc. Optional active pay-off, copper pre-heater, talc applicator, low smoke halogen free specialized screw, low-density screw, high-density screw, laser diameter gauge and PLC computer all-process control.
Specifications
| Machine model | HH-60+35 | HH+70+35 | HH-80+35 | HH-90+35 |
| Pay-off type | Active | Active | Active | Active |
| Pay off bobbin size(mm) | Φ400-630 | Φ400-630 | Φ400-630 | Φ630-800 |
| Insulation diameter(mm) | Φ0.8-8 | Φ1.5-12 | Φ2-20 | Φ3-25 |
| Extrusion capacity(kg/h) | 100 | 140 | 200 | 250 |
| Main machine power(hp) | 20 | 30 | 40 | 50 |
| Take up-motor power(hp) | 3 | 5 | 5 | 5 |
| Wire accumulate length(mm) | 200 | 200 | 200 | 200 |
| Take-up line type | Double axis 3hp | Double axis 3hp | Double axis 3hp | Double axis 3hp |
Technical Parameters
Brand of main parts:
1) Motor: Siemens
2) Driver: Yaskawa
3) Bearing: NSK, NACHI, ASCHI
4) Electric components: Omron
5) PLC controller: Siemens
6. Safety performances:
1) Switch-off at overpressure
2) Disabling signal at under temperatures
3) Stop at over temperature
3) Motor power limit
4) Emergency stop
5) Monitoring of tolerances and alarms
6) Monitoring of sensors
7. Machine pictures:
