Hydraulic XY-150 Water Well Drilling Rig / 150m Borehole Testing Equipment

Shandong Master Machinery Co., LTD
Hydraulic XY-150 Water Well Drilling Rig / 150m Borehole Testing Equipment thumbnail-1
Hydraulic XY-150 Water Well Drilling Rig / 150m Borehole Testing Equipment thumbnail-2
Hydraulic XY-150 Water Well Drilling Rig / 150m Borehole Testing Equipment thumbnail-3
Hydraulic XY-150 Water Well Drilling Rig / 150m Borehole Testing Equipment thumbnail-4
Hydraulic XY-150 Water Well Drilling Rig / 150m Borehole Testing Equipment photo-1
Hydraulic XY-150 Water Well Drilling Rig / 150m Borehole Testing Equipment photo-2
Hydraulic XY-150 Water Well Drilling Rig / 150m Borehole Testing Equipment photo-3
Hydraulic XY-150 Water Well Drilling Rig / 150m Borehole Testing Equipment photo-4
US$ 6500 - 6700 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HuaxiaMaster
Place of Origin:
China
Model Number:
XY-150
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
10 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HuaxiaMaster
Place of Origin China
Model Number XY-150
Type Rotary Drilling Rig
Certification ISO 9001
After-sales Service Provided No overseas service provided
Warranty 6 Months
Weight no
Dimension(L*W*H) no
Power Type Diesel
Voltage no
Usage Water Well
Condition New
Power(W) 11kw

XY-150 hydraulic water well drilling rig

1.Applications of XY-150 hydraulic water well drilling rig

· geological survey

· geophysical exploration

· road and high-rise building foundation exploration

· water wells

· blasting holes and other drilling projects

2. Parameters of XY-150 hydraulic water well drilling rig

Drilling depth(m)

150

Maximum opening diameter（mm）

219

The final hole diameter（mm）

73

Rod diameter（mm）

42/50

Spindle speed (r/min)

140/295/470/790/1010

Spindle stroke（mm）

450

Hoisting capacity (kn)

14

Steel wire diameter（mm）

9.3

Maximum pressure (mpa)

1.2

Working pressure (mpa)

0.7

displacement（l/min）

150

Hydraulic pump pressure (mpa)

1.2

Hydraulic pump rotation speed (r/min)

1800

Matched driving power (diesel engine and motor)

S1105 diesel engine and 11kw motor
