Mine Drill Equipment / Exploration Core Drilling on Sale

Shandong Master Machinery Co., LTD
Mine Drill Equipment / Exploration Core Drilling on Sale thumbnail-1
Mine Drill Equipment / Exploration Core Drilling on Sale thumbnail-2
Mine Drill Equipment / Exploration Core Drilling on Sale thumbnail-3
Mine Drill Equipment / Exploration Core Drilling on Sale photo-1
Mine Drill Equipment / Exploration Core Drilling on Sale photo-2
Mine Drill Equipment / Exploration Core Drilling on Sale photo-3
US$ 3800 - 4000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HuaxiaMaster
Place of Origin:
China
Model Number:
KY-250
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
QingDao
Delivery Detail:
10 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HuaxiaMaster
Place of Origin China
Model Number KY-250
Type Core Drilling Rig
Certification ISO 9001
After-sales Service Provided Engineers available to service machinery overseas
Warranty 6 Months
Weight main engine 275kg/backbone 40kg/operating floor86kg/power car 420kg
Dimension(L*W*H) 3400*1450*2000mm
Power Type Electric
Voltage 380V
Usage Coal
Condition New
Power(W) 30kw


1.Brief introduction of KY-250 full hydraulic drilling rig

The KY250 tunnel drilling rig is small in size and light weight, convenient installation and operation, good linkage and adjustable speed range. It is suitable for drilling at any angle in the tunnel or surface.

2.The parameter of KY-250 full hydraulic drilling rig

Drilling diameter

Φ36.5mm /Φ46.5mm

Drilling depth

250m（ø33 Steel drill rig）/200m（ø43 Steel drill rig）

Borehole angle

0°-360°

Spindle speed

400-1400r/min

Spindle output torque

150-400nm

Rated pulling force

40kn

Rated pulling speed

＞0.3m/s

Oil supply mode

double gear pump

Rated system pressure P

16mpa

Oil pump model

CBF-F71/10

Hydraulic oil model

antiwear hydraulic oil YB-N46/YB-N32 (winter)

Motor model

manual variable motor A6V80MA

Motor specification

30kw

Equipment weight

Main engine 275kg/backbone 40kg/operating floor86kg/power car 420kg


Master Machinery Group Co.,Ltd. China

Sales Manager： Jane Zhao

Sales hotline：86 537 18865479507

Tel: 18865479507

wahtsapp: 8618865479507

Website:


Waiting for your message ~. ）
