Tobee® SPR Rubber Lined Vertical Cantilever Slurry Pump is 100% interchangeable with Warman SP/SPR Vertical slurry pump, It is a kind of centrifugal slurry pumps submerged in sump to work.They are designed for delivering abrasive,large particle and high density slurries.These pumps have no need of any shaft seal and sealing water. They can also be operated normally for insufficient suction duties.Wet parts of type SP pump are made of abrasion-resistant metal. All parts of type TPR pump immersed in liquid are lined with rubber outer liner.They are suited to transport non-edge angle abrasive slurry.
Tobee® SPR Rubber Lined Vertical Cantilever Slurry Pump Specification:
Size (discharge): 40mm to 300mm
Capacity: 7.2~ 1492 m3/hr
Head: 5.5m ~ 47 m
Handing solids: 0 ~ 65mm
Concentration: 0%~ 70%
Material:High chrome alloy,Rubber,Polyurethane,Stainless steel etc
Tobee® SPR Rubber Vertical Submersible Pump Performance Parameter:
| Model |
Max.Power P (kw) |
Clear Water Performance |
Impeller dia. (mm) |
||||
| Capacity Q |
Head H (m) |
Speed n (r/min) |
Max. Eff. (%) |
||||
| m3/h | l/s | ||||||
| SPR40PV | 15 | 17.28-39.6 | 4.8-11 | 4–26 | 1000-2200 | 40 | 188 |
| SPR65QV | 30 | 22.5-105 | 6.25-29.15 | 5.5-30.5 | 700-1500 | 51 | 280 |
| SPR100RV | 75 | 64.8-285 | 18-79.2 | 7.5-36 | 600-1200 | 62 | 370 |
| SPR150SV | 110 | 108-479.16 | 30-133.1 | 8.5-40 | 500-1000 | 52 | 450 |
| SPR200SV | 110 | 189-891 | 152.5-247.5 | 6.5-37 | 400-850 | 64 | 520 |
| SPR250TV | 200 | 261-1089 | 72.5-302.5 | 7.5-33.5 | 400-750 | 60 | 575 |
| SPR300TV | 200 | 288-1267 | 80-352 | 6.5-33 | 350-700 | 50 | 610 |
Tobee® SPR Rubber Vertical Submersible Pump Component Diagram:
Tobee® SPR Rubber Vertical Submersible Pump Structural Drawing:
Tobee® SPR Rubber Vertical Submersible Pump Drive Type:
Tobee® SPR Rubber Vertical Submersible Pump Quality Control:
Tobee® SPR Rubber Vertical Submersible Pump After-sales Service:
As the slurry pump wet ends parts such as the impeller,volute liner,FPL insert,Throat bush are consumption parts and we could provide you always the qualified slurry pump parts within very short time.
Packing Transport Services
Considering the order pump size and we could provide case or pallet as per your need to make sure it safe enough during the long distance road and ocean shipping.have its own export company and so we could help you find the best ocean shipping solution and service for you from the goods out of factory to your destination.
Installation Services
Tobee Pump have more than 30 years experienced pump installation workers and are very aware of any onside application.We could provide abroad pump installation service and expect pump manufacturing and sales,abroad pump installation is getting more and more popular by our regular clients abroad.
Technical Support Services
Technical data sheet,Performance curve,General arrangement drawing,Operating manual will be sent within 24th for your checking, So Pls feel free to contact us If you have any need.
Tobee® SPR Rubber Vertical Submersible Pump On-Site Application:
1)Mine:Black, non-ferrous ore slurry material pump and all kinds of concentrate and tailings conveying.
2)Metallurgy:Transport various slurry for aluminium or steel manufacture.
3)Coal: Coal mining, washing and various coarse and fine coal slurry transportation.
4)Electricity:Remove power plant ash,wash ash,various ash dregs or ash slurry transportation.
5)Construction materials:Various mud sand slurry(such as Cement slurry) transportation.
6)Chemical: Phosphatic fertilizer or potassic fertilizer factory various abrasive slurry trasportation.
7)Water conservancy:Lake,river dredge, sediment,grit, High plastic clay Suction line to transportation.
Tobee® SPR Rubber Vertical Submersible Pump Spare parts:
| Size: | 40~300mm | Capacity: | 3~1560m/h |
|---|---|---|---|
| Head:: | 2~50m | Materials: | High Chrome Alloy,Rubber,Polyurethane Etc |
| Pump Type: | Vertical Sump Pump | Warranty: | One Year |
| Certificate: | ISO,CE,SGS,DNV | Application: | Mining,Coal,Metallurgy,Dredging,Power Plant,Sewage,Chemical Plant Etc |
| Type: | Rubber Verical Slurry Pump | Model: | SPR Vertical Slurry Pump |
| Name: | Rubber Vertical Submersible Pump |
