Home > Products > Vertical Slurry Pump > Standard 40mm Heavy Duty Cantilever Sump Slurry Pump
Standard 40mm Heavy Duty Cantilever Sump Slurry Pump
- 2000 Piece / Pieces per Month
- Tinajin Port
- T/T
- 7 days
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Brand Name: | Tobee | Place of Origin: | China | Model Number: | Warman standard |
Application: | Submersible | Fuel: | Other | Power: | Electric |
Usage: | Water | Theory: | Centrifugal Pump | Standard or Nonstandard: | Standard |
Structure: | Single-stage Pump | Pressure: | Other, mining industry |
Product Description
Tobee® TP40PV Cantilever Sump Pump works underwater for delivering heavy concentration abrasive & corrosive slurry with big particles. pump column is made by steel or elastomer covered steel, For rubber lined pump, all wetted parts are made by elastomer for delivering strong corrosion slurry.
Design features:
• Fully Cantilevered - Eliminates submerged bearings, packing, lip seals, and mechanical seals that other vertical slurry pumps typically require.
• Impellers - Unique double suction impellers; fluid flow enters the top as well as the bottom. This design eliminates shaft seals and reduces thrust load on the bearings.
• Large Particle - Large particle impellers are also available and enable passing unusually large solids.
• Bearing Assembly - The maintenance friendly bearing assembly has heavy duty roller bearings, robust housings, and a massive shaft.
• Casing - The metal pumps have a heavy walled abrasive resistant Cr27Mo chrome alloy casing. Rubber pumps have a molded rubber casing adhered to sturdy metal structures.
• Column and Discharge Pipe - The metal pump columns and discharge pipes are steel, and the rubber columns and discharge pipes are rubber covered.
• Upper Strainers - Snap in elastomer strainers fit in column openings to prevent overly large particles and unwanted refuse from entering casing of the pump.
• Lower Strainers - Bolt-on cast strainers on the metal pump and molded snap-on elastomer strainers on the rubber pumps protect the pump from oversize particles.
Tobee® TP40PV Cantilever Sump Pump Performance Parameter:
Tobee | Equivalent | Power P (kw) | Capacity Q (m3/h) | Head H (m) | Speed n (r/min) | Eff. η (%) | Impeller dia. (mm) | Max.particles (mm) | Weight (kg) |
TP(R)40PV | 40PV-SP(R) | 1.1-15 | 7.2-29 | 4-28.5 | 1000-2200 | 40 | 188 | 12 | 300 |
Tobee® TP40PV Cantilever Sump Pump Structural Drawing:
Tobee® Slurry Pump & Parts Inspection Process:
Stages of manufacture | Quality control activities | Standard |
Pump design | Appearance, size | GB/10888-89 |
Raw material arrival | Sampling, material chemical analysis | GB121.1-29-2008 |
Casting and composition | Material chemical analysis of pump parts | GB121.1-29-2008 |
Casting quality inspection | GB302-2012 | |
Key component machining | Dimension precision inspection | JB/T6879-93 |
Impeller balancing | GB061-2002 | |
General assembly | Procedure operation | GB2103-96 |
Hydraulic static test | GB064-2008 | |
Painting | Anticorrosion primer paint | JB/T4297-92 |
Epoxy coating | JB/T4297-92 | |
Performance test of pump unit | Capacity and head | GB157-1998 |
Vibration and noise | JB/T8097-05 | |
Bearing temperature | JB/T5295091 | |
Final inspection | Packaging of pump unit | GB0157-2008 |
Technical documents | GB0157-2008 | |
Spare parts and accessories | GB0157-2008 |
Tobee® TP40PV Cantilever Sump Pump On-site Applications:
• Mining | • Sump drainage | • Coal prep | • Mineral processing |
• Mill sumps | • Tunnel | • Tailings | • Chemical slurries |
• Ash handing | • Paper and Pulp | • Waste sludge | • Coarse sand |
• Lime mud | • Phosphoric acid | • Sump Dredging | • Mill grinding |
• Alumina Industry | • Power Plant | • Potash Fertilizer Plant | • Other industries |
Tobee® TP40PV Cantilever Sump Pump Dimensional Drawing:
