Overview
This is an E-Ink display HAT for Raspberry Pi, 6inch, 800x600 resolution, with embedded controller IT8951, communicating via USB/SPI/I80/I2C interface, supports partial refresh.
Due to the advantages like ultra low power consumption, wide viewing angle, clear display without electricity, it is an ideal choice for applications such as shelf label, industrial instrument, and so on.
Features
No backlight, keeps displaying last content for a long time even when power down
Low power consumption, basically power is only required for refreshing
Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards
USB/SPI/I80/I2C interface, for connecting with host boards like Raspberry Pi/Nucleo, etc.
Comes with development resources and manual (examples for Raspberry Pi/STM32)
Specifications
Operating voltage: 5V
Interface: USB/SPI/I80/I2C
Outline dimension: 138.4mm × 101.8mm × 0.954mm
Display size: 122.4mm × 90.6mm
Dot pitch: 0.153mm × 0.151mm
Resolution: 800 × 600
Display color: black, white
Gray scale: 2-16 (1-4 bit)
Full refresh time:
Total refresh power: 0.6W(typ.)
Total standby power: 0.3W(typ.)
Viewing angle: >170°
SPI Pinouts
| SYMBOL | DESCRIPTION |
|---|---|
| 5V | Power input |
| GND | Ground |
| MISO | SPI MISO pin |
| MOSI | SPI MOSI pin |
| SCK | SPI SCK pin |
| CS | SPI chip selection, low active |
| RST | External reset, low active |
| HRDY | Busy status output, low active |
e-Paper IT8951 Driver HAT Dimensions
