YINYAN Adhesive, Glue, Spper Glue, Rubber Silicone Sealant Mixing Dispersing Power Mixer

Official website:

YINYAN Adhesive, Glue, Spper Glue, Rubber Silicone Sealant Mixing Dispersing Power Mixer

Product Description

YINAYN Adhesive, Glue, Spper Glue, Rubber Silicone Sealant Mixing Dispersing Power Mixer, which is new and high efficient mixing equipment designed for universities, research institute and factory lab. It is quite suitable for the high viscous materials such as adhesive, silicone, lithium battery slurry etc. It has scraper to ensure no residue on the wall and bottom of container. It also can be equipped with extruder and slide rail to realize the integration of mixing and discharging.

The basic configurations of small planetary vacuum mixer:

1. Options of 1 set of scrapers;

2. Options of multi-containers, circulation, cooling, heating, heat preservation, thermal insulation

3. Automatic controlling programs, adjustable by frequency converter

4. Hydraulic lifting or pneumatic lifting

5. Operation under positive pressure or negative pressure

Working principle of small planetary vacuum mixer：

YINAYN small lab scale double planetary vacuum mixer, which is new and high efficient mixing equipment designed for universities, research institute and factory lab. It is quite suitable for the high viscous materials such as adhesive, silicone, lithium battery slurry etc. It has scraper to ensure no residue on the wall and bottom of container. It also can be equipped with extruder and slide rail to realize the integration of mixing and discharging. consists of reducer, planetary rack, mixing agitator, scrapers, mixing tank, hydraulic system and machine rack. When the planetary structure is running, the low-speed mixing shaft and high-speed dispersing shaft are working rotation and revolution together, it makes the materials under the strong shearing and kneading, to reach a complete uniform result. The planetary structure has scraper design, when it is working, it scrapes on the inner wall of the mixing tank, the mixing tank which is precision processed by large vertical lath machine and polished, then can make sure there is no residual on the inner wall. In additional, options of the scrapers which is equipped on the mixing structure, it can scrape the bottom of the mixing tank. To be ensure the mixing completely and keep the quality of the mixture product.
