GF food sanitary grade stainless steel single screw pump:
GF type stainless steel food sanitary grade single screw pump is made of stainless steel and non-toxic rubber material. The pump is mainly used in wine, undiluted beer malt and hops, milk powder, malted milk, starch, tomato sauce, soy sauce, fermented liquid, mash, honey, chocolate, milk, butter, cheese, and meat mixture slurry pump delivery and the pump can also be used in the pharmaceutical industry and toothpaste, etc.
Single screw pump is called as mono pump and eccentric rotor pump. It has the features of strong adaptability to the medium, steady flow, small pressure pulsation, high self-priming capacity. The pressure is 0.6 to 1.2MPa
Single screw pump can be used as a universal pump. Running speed can be high or low, the pump outlet rated pressure can increase with the pump series increase, each increase of a level, the pressure will increase 0.6mpa. so the pump has the use of a wide range in environmental protection, shipbuilding industry, petroleum industry, medicine, daily chemical, brewing industry, construction industry, mining industry, chemical industry, printing, paper industry.
Model |
Speed | Flow | Pressure | Motor | Head | Inlet | Outlet |
| r/min | m3/h | Mpa | kw | m | mm | mm | |
| G20-1 | 960 | 0.8 | 0.6 | 0.75 | 60 | Dy25 | Dy25 |
| G25-1 | 960 | 2 | 0.6 | 1.5 | 60 | Dy32 | Dy25 |
| G25-2 | 960 | 2 | 1.2 | 2.2 | 120 | Dy32 | Dy25 |
| G30-1 | 960 | 5 | 0.6 | 2.2 | 60 | Dy50 | Dy40 |
| G30-2 | 960 | 5 | 1.2 | 3 | 120 | Dy50 | Dy40 |
| G35-1 | 960 | 8 | 0.6 | 3 | 60 | Dy65 | Dy50 |
| G35-2 | 960 | 8 | 1.2 | 4 | 120 | Dy65 | Dy50 |
| G40-1 | 960 | 12 | 0.6 | 4 | 60 | Dy80 | Dy65 |
| G40-2 | 960 | 12 | 1.2 | 5.5 | 120 | Dy80 | Dy65 |
| G50-1 | 960 | 20 | 0.6 | 5.5 | 60 | Dy100 | Dy80 |
| G50-2 | 960 | 20 | 1.2 | 7.5 | 120 | Dy100 | Dy80 |
| G60-1 | 960 | 30 | 0.6 | 11 | 60 | Dy125 | Dy100 |
| G60-2 | 960 | 30 | 1.2 | 15 | 120 | Dy125 | Dy100 |
| G70-1 | 720 | 45 | 0.6 | 11 | 60 | Dy150 | Dy125 |
| G70-2 | 720 | 45 | 1.2 | 18.5 | 120 | Dy150 | Dy125 |
| G85-1 | 720 | 65 | 0.6 | 15 | 60 | Dy150 | Dy150 |
| G105-1 | 500 | 100 | 0.6 | 22 | 60 | Dy200 | Dy200 |
| G135-1 | 400 | 150 | 0.6 | 37 | 60 | Dy200 | Dy250 |
