Help CenterResin Bond Diamond Grinding Wheel for Carbide Steel
Related Products
-
Rotary Diamond Dresser,Dressing Precision Grinding Wheel,dressing Tool,Diamond Dressing Roll, Diamond DresserUS$ 0.1 - 0.5MOQ: 1 Piece -
Solid CBN Inserts for Cast Iron and Steel,Solid and Tipped CBN PCD Insert Cutting Tools,solid CbnUS$ 0.1 - 0.5MOQ: 1 Piece
-
Standard Wheel Shapes 1A1R, 1A1, 14A1, 6A2, 11A2, 12A2 45°, 12A2 20°, 11V2, 12V2, 11V9, 9A1, 9A3, 4A2, 12A9, 12C9, 14F1, 14EE1, 4BT9US$ 0.1 - 0.5MOQ: 1 Piece
-
Rotary Diamond Dresser,Diamond Dressing Roller,Electroplated Diamond Rotary Dresser,Hand Setting Dressers Wheel With CvdUS$ 0.1 - 0.5MOQ: 1 Piece
-
PCD Diamond Compact Tools,CBN Compact ToolsUS$ 0.1 - 0.5MOQ: 1 Piece
Resin bond grinding wheels are the most commonly used super abrasive product currently. our resin diamond wheel is suitable for surface grinding, OD grinding, centerless grinding, tool grinding, fine grinding ,double disc grinding and slot grinding of most precision workpieces.
Applications of resin diamond grinding wheel
Resin bond diamond grinding wheel is mainly used for machining tungsten carbide cutting tools, ceramic ,magnetic materials, silicon ,glass ,quartz and thermal spraying alloy ,etc
Advantages of resin diamond grinding wheel
* High cutting efficiency, good self-sharpening, less blocking, reducing the grinding burn occurs when the phenomenon of work
* Good flexibility will help to improve the surface roughness, mainly used for rough grinding, semi-fine grinding, polishing and other processes
* Compared to conventional silicon carbide , resin diamond wheel has good material removal rates, longer wheel life and lower grinding costs
* Resin bond diamond wheels generally remove material up to 10 times faster than metal bond wheels
1A1R Diamond Cutting Disc for optical glass, quartz and sapphire, etc
1A1 Diamond Grinding Wheel, flat diamond wheel for carbide grinding
More SuperHard resin diamond wheels are widely used for grinding carbide HVOF coated. The diameter from 25mm (1") to 915mm (36")
3A1 diamond wheel for grinding micro drill, 14A1 diamond wheel for grinding carbide rod
Diamond Cup Grinding Wheel. ( 1a2, 6a2, 11a2. etc )
CNC Tools Grinding Wheel. (1a1, 1v1, 11v9, 14a1, 14f1, etc)
More SuperHard services include fluting, gashing clear edge and relief angle, OD grinding of the tungsten carbide, HSS, milling cutter, reamer and drill, etc
Woodworking Tools Diamond and CBN Wheels. (4a2, 4b9, 1f1 diamond cbn wheel, etc)
Centerless Diamond Wheels. Diamond lapping disc. double disc diamond wheel
Back Grinding Wheel for Silicon Wafer. optical profile grinding wheel. Glass diamond wheel
Click on the video to view more product information
