Help CenterDiamond Insert,PCD,35 Deg, POLY-TECH DIAMOND,Turning Insert,Material PCD,Grade DA1000 SUMITOMO 16HQBZC
Related Products
-
Pcd Tip Grooving Insert Grooving Carbide Insert MRMN200/MRMN300/MRMN400 GroovingUS$ 0.1 - 30MOQ: 1 Piece -
PCD Diamond Grooving Inserts,PCD Tipped Grooving Cutters,PCD Veränderbar Interne Carbide Grooving TippsUS$ 0.1 - 30MOQ: 1 Piece
-
PDC Cutter Insert,pdc Cutters,synthenic PDC Cutter Inserts,pdc Button InsertUS$ 0.1 - 30MOQ: 1 Piece
-
Solid Cbn Insert Price,CBN Turning Inserts,Full Solid CBN Insert for Processing Grey CastUS$ 0.1 - 0.5MOQ: 1 Piece
-
Resin Bond Diamond Cup Squaring Wheel,Resin Bond Diamond Dry-Squaring Wheel ManufacturerUS$ 0.1 - 0.5MOQ: 1 Piece
MPN: 16HQBZC, SKU: G4884875
Product DetailsTurning Insert, Diamond, Insert Style CCMX, Insert Size 32.51, Chip-Breaker AW, Grade DA1000, Insert Application Finishing, Workpiece Compatibility Cast Iron (K), Relief Angle 7 Degrees , Inscribed Circle 3/8 In., Insert Thickness 0.1560 In., Nose Radius 0.0156 In., Insert Material PCD, Coating Uncoated, Cutting Direction Neutral, Rake Positive, For Use With Multiple Tool Holders, No. of Edges 4, Mounting Hole Dia. 0.1732 In., Mounting Style Screw-On
If you need any products, do not hesitate to contact
Skype:Annawng
WhatsApp:+8615617785923
@moresuperhard.com
What is the PCD material?PCD (Polycrystalline Diamond) is a synthetic diamond product that is produced by sintering together selected diamond particles with a metal matrix, using sophisticated technology. The diamond and matrix, when sintered together under high temperatures and pressures, creates a PCD tool blank that is high in uniform hardness and is abrasive resistant in all directions. This PCD diamond layer is then bonded to a tungsten carbide substrate, which provides strength and a brazable base to permit bonding to other metals.
More Superhard company has a simple mission—We help small business stay competitive!
We do this by offering thousands of great products at super low prices. Small businesses have historically been at a disadvantage to larger companies who can buy stuff at lower prices because of their size. We want to change that!
MORE has most of the products that the “big guys” have and we offer every single one of them at an everyday low price. There are no complex discount structures to understand. Every customer pays the same low price for an item—whether you want to buy one or one thousand!
Extrusion screws, barrels, turbine, case, housings, compressor hubs
|
|
insert type | size info | ||||
| L (mm) | I.C (mm) | S (mm) | R (mm) | D (mm) | ||
| RCGX060500 | 6.35 | 6.35 | 4.76 | |||
| RCGX090700 | 9.525 | 9.525 | 7.94 | |||
| RCGX120700 | 12.7000 | 12.7000 | 7.94 | |||
| RCGX151000 | 15.875 | 15.875 | 10.0 | |||
| RCGX191000 | 19.05 | 19.05 | 10.0 | |||
|
|
insert type | size info | ||||
| L (mm) | I.C (mm) | S (mm) | R (mm) | D (mm) | ||
| RCGX060400 | 6.35 | 6.35 | 4.76 | |||
| RCGX060500 | 6.35 | 6.35 | 5.0 | |||
| RCGX060700 | 6.35 | 6.35 | 7.94 | |||
| RCGX090700 | 9 | 9.525 | 7.94 | |||
| RCGX120700 | 12 | 12.7 | 7.94 | |||
|
|
insert type | size info | ||||
| L (mm) | I.C (mm) | S (mm) | R (mm) | D (mm) | ||
| RNMN060400 | 6 | 6.35 | 4.76 | 0 | ||
| RNMN120700 | 12 | 12.7 | 7.94 | 0 | ||
| RNMN160700 | 16 | 16 | 7.94 | 0 | ||
| RNMN190700 | 19 | 19.05 | 7.94 | 0 | ||
| RNMN201000 | 20 | 20.00 | 10 | 0 | ||
| RNMN251000 | 25 | 25.40 | 10 | 0 | ||
|
RCMN Solid CBN |
insert type | size info | ||||
| L (mm) | I.C (mm) | S (mm) | R (mm) | D (mm) | ||
| RCMN060400 | 6 | 6.35 | 4.76 | 0 | ||
| RCMN090400 | 9 | 9.525 | 4.76 | 0 | ||
| RCMN090600 | 9 | 9.525 | 6.35 | 0 | ||
| RCMN120600 | 12 | 12.7 | 6.35 | 0 | ||
| RCMN120700 | 12 | 12.7 | 7.94 | 0 | ||
| RCMN150700 | 15 | 15.875 | 7.94 | 0 | ||
| RCMN190700 | 19 | 19.05 | 7.94 | 0 | ||
|
SNMN Solid CBN inserts |
insert type | size info | ||||
| L (mm) | I.C (mm) | S (mm) | R (mm) | D (mm) | ||
| SNMN090308 | 9.520 | 9.525 | 3.18 | |||
| SNMN090412 | 9.525 | 9.525 | 4.76 | |||
| SNMN120712 | 12.700 | 12.700 | 7.94 | |||
| SNMN150704 | 15.875 | 15.875 | 7.94 | |||
| SNMN150708 | 15.875 | 15.875 | 7.94 | |||
| SNMN201020 | 20 | 20 | 10 | |||
|
CNMN Solid CBN |
insert type | size info | ||||
| L (mm) | I.C (mm) | S (mm) | R (mm) | D (mm) | ||
| CNMN090404 | 9 | 9.525 | 4.76 | |||
| CNMN090412 | 9 | 9.525 | 4.76 | |||
| CNMN120408 | 12 | 12.7 | 4.76 | |||
| CNMN120712 | 12 | 12.7 | 7.94 | |||
| CNMN120808 | 12 | 12.7 | 8.0 | |||
| CNMN160712 | 16 | 15.875 | 7.94 | |||
| CNMN160716 | 16 | 15.875 | 7.94 | |||
|
TNGN solid CBN |
insert type | size info | ||||
| L (mm) | I.C (mm) | S (mm) | R (mm) | D (mm) | ||
| TNGN110304 | 11 | 6.35 | 3.18 | |||
| TNGN110308 | 11 | 6.35 | 3.18 | |||
| TNGN110312 | 11 | 6.35 | 3.18 | |||
| TNGN160404 | 16 | 9.25 | 4.76 | |||
| TNGN160408 | 16 | 9.25 | 4.76 | |||
| TNGN160412 | 16 | 9.25 | 4.76 | |||
