Danfoss valves Type STC100-125D STC DN150 Shut-off valves Features
• Applicable to all common refrigerants including R717 and non corrosive gases/liquids dependent on sealing material compatibility
• Available with:
– Heavy duty industrial handwheel for
frequent operation
– Vented cap for infrequent operation
• Available in angle and straight versions with standard bonnet for installation in normal insulated systems
• The valves and caps are prepared for sealing, to prevent operation by unauthorized persons
• Internal metal backseating
– DN 15 - 150 (½ - 6 in.)
• Can accept flow in both directions
• Max. working pressure: 25 bar g (365 psi g)
• Temperature range: –50/+150 o C (–58/+302 o F)
• Design specification according to DIN 3158
Danfoss valves Type STC100-125D STC DN150 Shut-off valves product introduction
STC are angleway and straightway shut-off valves which are designed to meet industrial refrigeration application requirements.
The valves are designed to give favourable flow characteristics and are easy to dismantle and repair when necessary.
Danfoss valves Type STC100-125D STC DN150 Shut-off valves selection
STC 15 A ANG SHUT-OFF VALVE CAP 148B4600
STC 15 A ANG SHUT-OFF VALVE HANDWHEEL 148B4601
STC 20 A ANG SHUT-OFF VALVE CAP 148B4602
STC 20 A ANG SHUT-OFF VALVE HANDWHEEL 148B4603
STC 25 A ANG SHUT-OFF VALVE CAP 148B4604
STC 25 A ANG SHUT-OFF VALVE HANDWHEEL 148B4605
STC 32 A ANG SHUT-OFF VALVE CAP 148B4606
STC 32 A ANG SHUT-OFF VALVE HANDWHEEL 148B4607
STC 40 A ANG SHUT-OFF VALVE CAP 148B4608
STC 40 A ANG SHUT-OFF VALVE HANDWHEEL 148B4609
STC 50 A ANG SHUT-OFF VALVE CAP 148B4610
STC 50 A ANG SHUT-OFF VALVE HANDWHEEL 148B4611
STC 65 A ANG SHUT-OFF VALVE CAP 148B4612
STC 65 A ANG SHUT-OFF VALVE HANDWHEEL 148B4613
STC 80 A ANG SHUT-OFF VALVE CAP 148B4614
STC 80 A ANG SHUT-OFF VALVE HANDWHEEL 148B4615
STC 100 A ANG SHUT-OFF VALVE CAP 148B4616
STC 100 A ANG SHUT-OFF VALVE HANDWHEEL 148B4617
STC 125 A ANG SHUT-OFF VALVE CAP 148B4618
STC 125 A ANG SHUT-OFF VALVE HANDWHEEL 148B4619
STC 150 A ANG SHUT-OFF VALVE CAP 148B4620
STC 150 A ANG SHUT-OFF VALVE HANDWHEEL 148B4621
STC 15 A STR SHUT-OFF VALVE CAP 148B4622
STC 15 A STR SHUT-OFF VALVE HANDWHEEL 148B4623
STC 20 A STR SHUT-OFF VALVE CAP 148B4624
STC 20 A STR SHUT-OFF VALVE HANDWHEEL 148B4625
STC 25 A STR SHUT-OFF VALVE CAP 148B4626
STC 25 A STR SHUT-OFF VALVE HANDWHEEL 148B4627
STC 32 A STR SHUT-OFF VALVE CAP 148B4628
STC 32 A STR SHUT-OFF VALVE HANDWHEEL 148B4629
STC 40 A STR SHUT-OFF VALVE CAP 148B4630
STC 40 A STR SHUT-OFF VALVE HANDWHEEL 148B4631
STC 50 A STR SHUT-OFF VALVE CAP 148B4632
STC 50 A STR SHUT-OFF VALVE HANDWHEEL 148B4633
STC 65 A STR SHUT-OFF VALVE CAP 148B4634
STC 65 A STR SHUT-OFF VALVE HANDWHEEL 148B4635
STC 80 A STR SHUT-OFF VALVE CAP 148B4636
STC 80 A STR SHUT-OFF VALVE HANDWHEEL 148B4637
STC 100 A STR SHUT-OFF VALVE CAP 148B4638
STC 100 A STR SHUT-OFF VALVE HANDWHEEL 148B4639
STC 125 A STR SHUT-OFF VALVE CAP 148B4640
STC 125 A STR SHUT-OFF VALVE HANDWHEEL 148B4641
STC 150 A STR SHUT-OFF VALVE CAP 148B4642
STC 150 A STR SHUT-OFF VALVE HANDWHEEL 148B4643
