Help CenterNEMA34 Two-phase Stepper Motor
Related Products
Motor Model |
Flange(mm) |
Holding torque (Nm) |
Rated Current (A) |
Rotational Inertia(g.cm²) |
Weight (Kg) |
Motor Length(mm) |
Diameter of Axle(mm) |
Length of Axle(mm) |
Flat/keyslot (mm) |
SM2-930L |
86 |
3.0 |
4.5 |
1100 |
1.6 |
60 |
14(keyslot) |
37 |
5*5*25 |
SM2-945L |
86 |
4.5 |
4.5 |
1400 |
2.1 |
80 |
14(keyslot) |
37 |
5*5*25 |
SM2-982L |
86 |
8.2 |
4.5 |
3600 |
3.6 |
115 |
14(keyslot) |
37 |
5*5*25 |
SM2-9A2L |
86 |
12.0 |
4.5 |
5400 |
5.0 |
155 |
14(keyslot) |
37 |
5*5*25 |
SM2-985H |
86 |
8.5 |
6.0 |
2800 |
3.8 |
118 |
14(keyslot) |
37 |
5*5*25 |
SM2-9A0H |
86 |
10.0 |
5.5 |
3600 |
5.0 |
156 |
14(keyslot) |
37 |
5*5*25 |
Recommended Stepper Driver：SD2118
Motor Options:
1. Double-end with shaft
2. Brake
3. Encoder.（1000 line incremental encoder)
4. Wire with Connectors
For more details please refer to MOTEC 2-phase Intelligent Stepper System Catalogue and MOTEC Intelligent stepper drive user’s manual or send an inquiry to whan@vip.sina.com
