Surveillance Telescopic Pneumatic Light Tower

Overview

              It can help lamplight, camera, Antenna, mobile and other equipment rise and drop to a predetermined height after its work. It also plays an important role in natural disasters, emergency rescue at night and lightning at the Golf course and large football field.Our product has the advantages of large play load, low noise, fast lifting, strong buffering & stable performance and the like. With high strength aluminum alloy, our products can easily meet the needs of different height and load in different places. It can be installed on the ground or on the vehicle to ensure the application effect.

Application:
Microwave Antenna Masts Tower, Radio Communication Towers, Surveillance Camera Elevation, Sensor Elevation, Data Gathering, Atmosperic Measurement, Airfield Weather Stations, Oil Field Exploration, Border Security Application......

Specifications of surveillance telescopic pneumatic light tower

1> Extended height: 5.0m
2>Retracted height: 1.75m
3>Diameter range: 40--90mm
4>Loading: 35kg
5>Collar style: non-locking collar
6>Number of sections: 4 sections
7>Max Working pressure：0.20MPA
8>Working temparature:-15--+50C
9>Lifting speed:2.0m per minute

Installation Instructions:

1）The Mobile 5m pneumatic antenna lifter can be installed on the ground, or on the vehicle. No matter where to install, its installation shall keep vertical with the ground.Tilted telescopic antenna mast will affect the rise and fall of itself, and if the lifting rod tilts seriously or maintain a long time, damage and danger could not be avoided.
2）The Mobile 5m pneumatic antenna lifter needs to be installed on a fixed object, without any shaking, such as walls, car body, or pile. At least two fixed points will be installed, and one point must be installed on the body of the telescopic antenna mast. And the distance between two points should be longer than 2/3 of the height of telescopic antenna mast. Its connection must be solid and reliable.

Warranty period

Except the damages due to misuse, unauthorized modification and man-made sabotage, the damaged parts will enjoyed free after-sales maintenance within one year’s time from the date of delivery on the condition that the buyer himself will bear the shipping cost back and forth and the said damage should be confirmed by the seller through photos and description.

NOTE:

For the model NO.: AT7 for the mast with cable design we have done for our clients, if you need cable, cable size need customers provide.

                                  AT8 for the mast without the cable and the lock

                                  AT9 for the mast with the lock
