1. The applications of HZ-200YY drilling rig
HZ-200YY drilling rig is mainly used for water well,field irrigation well,engineering water well,precipitation well and so on;geological general investigation and exploration,road and tall building foundation exploration, holes in concrete structure,river levees.
2. The features of HZ-200YY drilling rig
l The highest speed can reach 1045r/min with 5 gears, improved drill efficiency
l Adopted 53 x 59 drilling rod, high rigidity and strong delivery torque
l Equipped with national patent technology---taper clutch, make the machine easy to operate and free maintenance.
l Use large module planetary gear and add supporting frame, highly increased hoisting and braking ability of the winch.
l Vertical spindle are fixed by four groups of bearings to ensure that the rotary machine is rigid enough for gravel layer and other complex geological conditions.
3. The specifications of HZ-200YY drilling rig
Maximum open hole diameter |
300mm |
End hole diameter |
75mm |
Drilling pipe diameter |
50mm |
Drilling angle |
90° |
Drilling rig weight (without power) |
975kg |
triangular belt |
B950 x 4; B1700 x 3 |
Active move distance |
300mm |
Power |
diesel engine 20hp |
electric motor 15kw | |
Spindle | |
Spindle rotating speed |
64/128/287/557r/min |
Spindle stroke |
450mm |
Windlass | |
Maximum lifting power of a single rope |
2400kg |
Lifting speed of a single rope |
0.41/0.82/1.64m/s |
Wire rope diameter |
13mm |
Drum capability |
35m |
Band-type break diameter |
260mm |
Band-type break belt width |
70mm |
Mud pump | |
Model |
horizontal single-urn twin-action |
Displacement |
diesel engine 170l/min |
electric motor 150l/min | |
Maximum pressure |
3mpa |
Work pressure |
1.5mpa |
Water inlet pipe diameter |
40mm |
Water outlet pipe diameter |
30mm |
Triangular belt |
B1728mm |
