Help Center100M Depth Hydraulic Rotary Diamond Rock Core Machine Artesian Well Drilling Rig
Related Products
-
In Stock Geological Exploration Small Hydrualic Drilling Rig Machine For SaleUS$ 4000 - 8000MOQ: 1 Set -
In Stock Air Driven Power Hammer Impact Drilling Rig Machine For Water WellUS$ 4000 - 7500MOQ: 1 Set
-
200 M Hydraulic Rotary Water Well Drilling Rig Rock Core Sample For SaleUS$ 4000 - 7500MOQ: 1 Set
-
6.5 Hydraulic Tower Long Stand Easy Load 600M Water Well Rock Core Sample Drilling RigUS$ 6000 - 7500MOQ: 1 Set
-
Water Well Drilling Rig Diamond Core Machine Hydraulic Rotary Drilling Machine For SaleUS$ 6000 - 7500MOQ: 1 Set
Keywords: Mining Core Drilling Machine, core sampling drilling rig, hydraulic press machine, geological prospecting rigs
1. Applications of XY-100 hydraulic drilling rig
XY-100 core drilling rig is widely used for Water well drilling, Geological Exploration and Prospecting, Geothermal wells, Blast-hole, Irrigation projects, etc.
2. Specifications of XY-100 hydralic drilling rig
Drilling depth |
110 |
Maximum open hole caliber |
220mm |
End hole caliber |
75mm |
Drill rod caliber |
50mm /42mm |
Drilling angle |
90 |
Drilling rig weight (Exclude diesel engine) |
610kg |
Unity machine dimensions |
2.1*0.9*1.3m |
Spindle | |
Spindle speed |
130/300/480/730/830/1045 r/min |
Spindle stroke |
450mm |
Hoist | |
Max. lifting capacity with single rope |
1600kg |
Lifting speed with single rope |
1.06/0.67/0.32 m/s |
Wire rope caliber |
13mm |
Wire rope cubic measure |
35mm |
Hug floodgate caliber |
254mm |
Hug floodgate belt width |
50mm |
Distance between drill and hole |
230mm |
Mud pump | |
Type |
Horizontal single-urn twin-action |
Displacement (with diesel engine/electric motor) |
170l/min |
Max. pressure |
1.5mpa |
Work pressure |
0.7mpa |
Power | |
Diesel engine |
S1100 |
Electric motor |
Y160M-4 / 10KW |
