FY300 Crawler Pneumatic Rock Bore Hole Drilling Machine Water Well Drilling Rig
US$ 5000 - 7000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huaxia Master
Place of Origin:
China
Model Number:
FY 300
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
7 days
Related Products
-
Made In China Diamond Core Machine Hydraulic Press Water Well Drilling Rig On PromotionUS$ 4000 - 8000MOQ: 1 Set -
In Stock 600M Diamond Core Machine Hydraulic Press Water Well Drilling Rig For SaleUS$ 6000 - 7500MOQ: 1 Set
-
Diamond Core Machine Rock Breaker Borehole Drilling Water Well Drilling Rig For SaleUS$ 6000 - 7500MOQ: 1 Set
-
In Stock Hydraulic Rotary Diamond Core Machine Water Well Drilling Rig On PromotionUS$ 4000 - 7500MOQ: 1 Set
-
Rotary Working 6.5 M Hydraulic Tower And Stand Diamond Core Machine For Water WellUS$ 4000 - 7500MOQ: 1 Set
Brand Name
Huaxia Master
Place of Origin
China
Model Number
FY 300
Type
Rotary Drilling Rig
Certification
iso 9001
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
one year
Weight
8 T
Dimension(L*W*H)
4350*1850*2750 mm
Power Type
Diesel
Voltage
380 V
Usage
Water Well
Condition
New
Power(W)
85 KW
The applications of FY300 crawler pneumatic water well drilling rig
civil engineering drilling
geothermal drilling,
drilling with large diameter and deep drilling footage
It’s fast, flexible and efficient
The specifications of FY300 crawler pneumatic water well drilling rig
Model |
FY300 |
|
Gross weight |
t |
8.8 |
Dimension |
mm |
4350*1850*2750 |
Aperture |
mm |
140-325 |
Drilling depth |
m |
300 |
Feed stroke |
mm |
6000 |
Travel speed |
km/h |
2 |
Grade ability |
max. |
30° |
Rising height from ground |
mm |
230 |
Wind pressure |
mpa |
1.7-3.3 |
Air consumption |
m³/min |
23 |
Engine power |
kw |
85 |
Rotary speed |
rpm |
55-115 |
Rotation torque |
n.m |
7200-8500 |
