Mining Machinery Pendulum Feeder Machine,Swaying Feeder

ShiChengXian JinChuan Mineral Equipment Manufacturing Co.,Ltd
Mining Machinery Pendulum Feeder Machine,Swaying Feeder thumbnail-1
Mining Machinery Pendulum Feeder Machine,Swaying Feeder thumbnail-2
Mining Machinery Pendulum Feeder Machine,Swaying Feeder thumbnail-3
Mining Machinery Pendulum Feeder Machine,Swaying Feeder photo-1
Mining Machinery Pendulum Feeder Machine,Swaying Feeder photo-2
Mining Machinery Pendulum Feeder Machine,Swaying Feeder photo-3
US$ 1000 - 10000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
JInchuan
Place of Origin:
China
Model Number:
Series
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen or as request
Delivery Detail:
5 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name JInchuan
Place of Origin China
Model Number Series
Certification ISO:9001
After-sales Service Provided Engineers available to service machinery overseas
Warranty 12 months
Weight Depend on model
Dimension(L*W*H) Depend on model
Power Type Electric
Application Mining, chemical, building material, concentrating and coal, etc.
Condition New
Power(W) Depend on model
Capacity(t/h) Depend on model
Product Description

  The machine is installed beneath the discharging opening of ore bin. Minerals fall in the ore feeding box from ore bin. When it works, via couple, electric motor drive turbine reducer to operate; the pendulum plate of chute begin the reciprocal movement through eccentric wheel on the output shaft of turbine reducer. So, the mineral feeding process is finished. The mineral feeding quantity can be controlled by adjusting eccentric wheel or regulating the revolving speed of motor.

Main Features

   Used to beneficiation, coal, chemical engineering and other industries, to put the granular material from storage chute into those different input device via funnel. The pendulum feeder is not suitable for conveying dry powdery or too large granularity material, or it would be appeared dust pollution and discharge outlet clogging.
1. Steady vibration, safe operation, durable life.;
2. Flux can be changed and controlled;
3. The machine can be adjusted steadily, low noise, low electricity consumption;
4. Simple structure, safe operation, light weight, small volume, easy to maintenance

Specification

Product Application

  The pendulum feeder mostly used for ball mill as the feeder device of gathering belt conveyor.

Used to beatification, coal, chemical engineering and other industries, put the granular material from storage chute into those different input device via funnel.

The Pendulum feeder is used to feed the materials into the bin. It is suitable for concentrating coal chemical industry and other departments to deliver the grain to various sets of acceptable materials from the store chute by the filter.
