Features:
1. Double O-type fuselage with high strength, high-rigidity steel plates welded together, and the overall tempering treatment, effectively eliminate the internal stress to ensure long-term stability of the machine.
2. Adopts Siemens special CNC system and match up digital AC servo motor to make it stable and reliable.
3. The transmission system use the international brand with high precision, big guide the ball screw, linear guide rail are high precision and good performance.
4. Adopt full float type pneumatic clamp, when stamping with plate float from top and bottom, effectively eliminate the stamping spare force, to improve the processing accuracy.
5. Adopt the imported clutch, brake in time, top and bottom dead spots positioning accuracy.
6. Adopt AMD-H punch press special mold station, easy to replace and long service life, durable to use and effective improve mold service life.
7. Use thick plate special mold, adopt oblique edge design, can reduce noise and reduce 20% stamping resistance, improve punching accuracy and extend the service life of the mold.
Advantages:
1. Inspected by the Inspection Institution of Bureau Veritas Certification.
2. 100% QC inspection Before Shipment.
3. CE certificate assure you our quality.
4. Customized, Meet your needs.
5. Good stability, Low failure rate (technical maturity, technical precipitation, skilled workers).
6. Exquisite appearance (mature craft).
7. Large factories, Prompt delivery.
Application:
The machines are mainly used for punching holes on the plate used in cars trabecular, automotive girder, thick plate ventilation holes, steel construction, steel bridge, ship building and those sort of applications.
Product specification:
No. |
Specification |
Parameter |
1 |
Transmission mode |
Hydraulic |
2 |
Punch force |
800-2000KN |
3 |
Power rating |
15-50KW |
4 |
Max. Processing plate size |
1500*3000mm 1500*6000mm(Re-position) |
5 |
Max. Plate thickness |
6-25mm(carbon steel) |
6 |
Max. Punch diameter |
Φ80mm |
7 |
Max. Traversing speed |
30m/min |
8 |
Stamping stroke |
100mm |
9 |
Ram stroke |
35mm |
10 |
Throat depth |
1500mm |
11 |
X/Y axis stroke |
X=3000mm Y=1500mm |
12 |
Punching frequency |
50-100hpm |
13 |
Hole accuracy |
±0.1mm |
14 |
Number of station |
2-12 stations |
15 |
Max. Loading weight |
600kg |
16 |
Controlled axis |
2 axis |
17 |
Air pressure |
≥0.6mpa |
18 |
Quantity of clamps |
3 |
19 |
Clamp construction |
All floating |
20 |
Reposition device |
Yes |
21 |
CNC system |
Siemens |
22 |
Machine weight |
8-20T |
23 |
Power supply |
380V,50HZ, 3Phase or customized |
24 |
Overall dimensions |
7000*5500*2710mm or customized |
