JC-23-TCT Saw Blade Sharpening Machine
US$ 5.00 - 15.00
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Chine chern
Place of Origin:
Taiwan, China
Model Number:
JC-23
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen/GuangZhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JC-450C-saw Blade Sharpening MachineUS$ 27,000 - 29,000MOQ: 1 Set -
CNC GrindingMachine for Carbide Saws (Performance)US$ 15,000 - 60,000MOQ: 1 Set
-
SU-1200-Friction Saw Blade Grinding MachineUS$ 15,000 - 60,000MOQ: 1 Set
-
CV450-Circular Knives Grinding MachineUS$ 15,000 - 70,000MOQ: 1 Set
-
BR-650-Saw Blade Grinder for HSS-TCTUS$ 15,000 - 70,000MOQ: 1 Set
Brand Name
Chine chern
Place of Origin
Taiwan, China
Model Number
JC-23
After-sales Service Provided
Overseas service center available
JC-23-TCT Saw blade sharpening machine
Features:
1.CNC control,friendly interface.
2.It is used for sharpening Tungsten steel circular saw blade .
3. 8.1'' TFT Colorful monitor
The automatic carbide saw grinder machine is suitable for grinding various carbide saws
used in woodworking,steel,Plastic industries etc.
Technical parameters:
| Diameter of saw blade | 100-810mm/4-32'' | ||
| Saw bore diameter | 10-120mm | ||
| Saw blade thickness | 8mm | ||
| Tooth pitch | 8-70mm | ||
| High-low difference | 3mm | ||
| Speed | 25m/s | ||
| Grinding speed | 0.5-10mm/s | ||
| Grinding capacity | 20teeth | ||
| Clearance angle | 6°-45° | ||
| Rake or hook angle | -30°-40° | ||
| Bevel grinding at the tooth top | 0°-45° | ||
| Bevel grinding at the tooth face | 0°-30° | ||
| Drive power | 3.7/4.2KW | ||
| Wheel O.D* Bore O.D | 125mm*32mm | ||
| Machine dimension(L*W*H) | 1650*1300*2000/1900*1300*2100 | ||
| Packing dimension(L*W*H) | 1800*1450*2100/2020*1450*2200 | ||
| Net/Gross weight | 1050kg/1200kg | ||
Machine Parts:
For Tungsten Carbide Saw Blade Grinding:
