CNC Pipe Bending Machine For Metal Furniture
Characteristics:
1. Decomposition action can be tryout at the time of bending so as to observe interfering points, amend movement and improve efficiency.
2. Material feed axis will auto detect before its operation to avoid the clash with machine
3. The position of material entrance, safety, input mould interfere and conduct mould interfere of material feed trolley can be set by hand and auto memorized to cancel man measurement error and loss of machine collision.
4. The documents displayed on the screen can be printed by connecting a printer
5. It is equipped with auto adding oil system to decrease friction between bending tubes, prolong use life of mandrel and guarantee the quality of bending tubes.
6. Electric system is matched with heat exchanger for auto cooling; you can also select numerical control air conditioner to maintain the use life of electric system.
7. Documents are protected by key to prevent it from being amended by random.
8. XYZ coordinate can be automatically changed into YBC process value.
9. Material feeding way can be selected in straight or clip feed according to different needs.
10. Feed axis, bending axis and rotary axis adopts the servo motor drive with high precision and excellent stability.
Parameters:
Model | JC38CNC×2A-1S | |
Max carbon steel tube material (1.5D bending radius ) | Φ38.1×2.0t | |
max stainless steel tube material (1.5D bending radius) | Φ31.75×2.2t | |
max feeding distance | 2100mm | |
Feeding methods | . deliver directly | |
max bending radius | 175mm | |
Max bending degree | 190° | |
each tube fitting can be set bending number | 16 | |
Can be set the number of tube fitting files | 400 | |
Working speed | Bending speed | Max.45°/s |
Rotary speed | Max.270°/s | |
Feeding speed | Max.900mm/s | |
Precision | Bending degree | ±0.15 ° |
Rotary degree | ±0.1° | |
Feeding length | ±0.1mm | |
Date input | Working value(Y.B.C) | |
Rotary servo motor power | 400W | |
feeding servo motor power | 1.0KW | |
Oil-pressure motor power | 5Hp | |
Weight (Kg) | 2200KG | |
Size L.W.H(cm) | 350×155×110 | |
Pipe Bending Samples :
