NC Hydraulic Double Head Pipe Bending Machine

FOB Price

US$ 5.00 - 15.00 / Set

1 Set(Min. Order)

Port ShenZhen/GuangZhou
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Chine Chern		Place of Origin	Guangdong, China
Model Number	JC-50/90degree		After-sales Service Provided	Engineers available to service machinery overseas

Product Description

NC Hydraulic Double Head Pipe Bending Machine

Features:

double-head high speed bending machine, with NC control, makes your operation and program’s setting easy. Applying for automobile, seat, motorcycle, fender-guard and the furniture .

1. Standard type: the secondary space angle is not rotator, the double-head can adjust bending angle of tube from 0 to 185 by random, but the material should be considered.

2. Rotator type: the secondary space angle is rotator; the double-head can adjust from 0 to 90 by random.

It adopts PLC control for convenient operation and easy maintenance.

Optional operation with full- circulation or semi- circulation.

You can choose the operation of 1 or more at a time according to outer diameter of different materials.

standard accessories: a group of mould, a group of block foot.

Parameters:

Specification/Model	Unit	JC-50A	Remark
Max bending capability	mm	Φ50×2	1. The Minimum bending diameter based on the pipe diameter 2.The Max bending diameter can according to the customer’s requirement 3.The Max length of mandrel can according to customer’s requirement
Max bending radius	mm	R200
Min bending radius	mm	According to pipe OD
Max bending angle	Degree	180
Rang of double bending center	mm	170-2000
Control System		NC Control
Max. Hydraulic Pressure	Mpa	12
Hydraulic System Control		Electromagnetic Valve
Oil Tank Capacity	L	125
Measurement	mm	3600 x 1100 x 1370
Weight of Machine	Kg	1900

Bending Samples:

Machine Photo:
