TCT Saw blade sharpening machine
- 20 Set / Sets per Month
- ShenZhen/GuangZhou
- T/T Credit Card
Product Details
Brand Name: | Chine Chern | Place of Origin: | Taiwan | Model Number: | JC-18 |
After-sales Service Provided: | Overseas service center available |
Product Description
TCT Saw blade sharpening machine
Characteristics:
Features:
1. Grinding all kind of tooth in one single pass SJ-18 offers all kind of tooth grinding in one single pass,includes: Woodworking Teeth, Aluminum Teeth.
2. PLC controlled User friendly Interface Computer control parameter setup, only need to input: Tooth type classification, Total tooth, grinding amount and Angles,The system will deal with the automatic procedure. Bring grinding result better, accuracy and operation better than ever.
3. 5.4” Monitor and Graph input 5.4” TFT monitor with graphic display, you only need to input parameter for easy grinding.
Main technical parameters:
Model | JC-18 | |||||
Diameter of saw blade | 220mm-700mm | |||||
Saw blade bore diameter | 10mm-120mm | |||||
Thickness of saw blade | 8mm | |||||
Tooth pitch | 8-70mm | |||||
High-low difference | 3mm | |||||
Circular velocity | 25m/s | |||||
Grinding speed | 0.5-10mm/s | |||||
Grinding capacity | 20teeth/min | |||||
draght angle | 6°-45° | |||||
Throat angle | 0°-40° | |||||
Top bevel angle | 0°-45° | |||||
Teeth bevel angle | 0°-30° | |||||
Motor | 1.7KW/2.3HP | |||||
Voltage | 3-phase 380V 50HZ Or as per the request | |||||
Wheel outer O.D*Wheel bore O.D | 125mm*32mm | |||||
Machine dimension | 1450×1400×1800mm | |||||
Packing dimension | 1600×1550×2000mm | |||||
Net weight/Gross weight | 650/800kg | |||||
Spindle speed | 5000RPM | |||||
Grinding motor | 0.75KW/1HP | |||||
Water pump motor | 0.1KW/ 1/8HP |
Machine Photo :
Certificate :
Company Profiles :
with decades hard work and accumulated experiences, We have acquired fourty invention
patent,Utility model and appearance patent.Meanwhile, We have passed ISO9001:2008 quality system certificate, Government-issued Guangdong Province private technology enterprises, high-
tech enterprises, private enterprises and other honors.
The products include Super hard metal bar cold saw machine series, Chipless metal pipes circular saw machine series,Copper aluminum non-ferrous high-speed precision circular saw machine series,Metal pipe/bar end chamfer machine series,Circular saw blade sharpening machine series,Automatic pipe bending and forming Machine series , Six categories eighty models , Also provide customized complex process
Machine , all kinds of circular saw blade . Wide Application range contains Nautical
aviation and aerospace industry, military industry, high-speed rail and rail transportation
industry, auto industry, precision parts, medical and fitness equipment industry, mechanical and electrical and electronic industry, lighting and furniture decoration forty industries .
