The machine is specially designed for embossed aluminum foil which the thickness is less than 0.1mm, any aluminum foil which the thickness exceed 0.1mm or the other material the rigidness
exceed the Aluminum foil are all prohibited.
1. Thickness of Aluminum foil : ≤0.1mm
2. The maximun width of foil :1250mm
3. The maximum outer diameter of foil roll :1000mm
4. Embossing speed : 0~30m/min,(Rating speed:26-30m/min)
5. The maximum length aluminum foil winding: 1200m
6. Installed capacity: 9Kw
7. Equipment size : 3800*2200*1600mm
8. Total weight : ~2500Kg
9. Winding quality requirement: equal length on both side, no wave shape, no tower shape, no perforation,
lateral channeling layer tolerance is less than ±1.0mm
10. Normal service life :30,000,000 meters
